Rubber non-rotor vulcanization Tester
Non-rotor vulcanizer is a rubber processing industry control rubber material quality, rapid inspection and rubber basic research and application instrument, for rubber optimization formula combination provides accurate data, can accurately measure the coke time, positive vulcanization time, vulcanization index and large, small torque and other parameters.
Reference standard:
ASTM D5289-95. ISO 6502-1999(E)， GB/T 16584-1996
Technical parameters:
Temperature measurement range: 0--200℃
Setting range: 0--200℃
Temperature display range: 0--200℃
Set time range: 0-200 minutes
Torque measuring range: 0-5N.m, 0-10N.m, 0-20N.m
Power supply: AC 220V±10%, 50±1Hz, must be well grounded
Compressed air: 0.32Mpa, controlled by pneumatic control valve
Swing frequency: 100 times/min (about 1.7HZ)
Ambient temperature: 0-40 ℃， relative humidity is less than 80%, the air does not contain corrosive gases
