Solid electrolyte analysis device
Standard
ISO 9001:2015(Quality Management System)
ASTM E1970-21(Standard Guide for Electrochemical Impedance Spectroscopy)
IEC 62660-2(Secondary Lithium-Ion Cells for Propulsion of Electric Road Vehicles)
RoHS Compliance(Restriction of Hazardous Substances)
CE Certification(Conformité Européenne)
Product Advantages
Unmatched Precision
Sub-micron level ionic conductivity measurement (±0.01% error margin) for cutting-edge battery R&D.
Advanced electrochemical impedance spectroscopy (EIS) with frequency range up to 10 MHz.
Rapid Testing Workflow
80% faster analysis compared to traditional systems via AI-driven automation.
Multi-sample parallel testing capability (up to 16 samples simultaneously).
User-Centric Design
Intuitive touchscreen interface with 15+ language support (English, Chinese, German, Japanese, etc.).
Modular architecture for easy upgrades and maintenance.
Durability & Safety
Military-grade enclosure (IP67 rating) resistant to dust, moisture, and vibrations.
Overvoltage/overcurrent protection with real-time self-diagnostics.
Global Connectivity
Cloud-based data synchronization via AES-256 encrypted platform.
Compatibility with LabVIEW, MATLAB, and Python for seamless integration into existing workflows.
Product Features
Non-Destructive Testing (NDT): Preserves sample integrity through contactless impedance measurement.
Temperature Control System: Precision Peltier module (-20°C to 80°C ±0.1°C stability).
Automatic Calibration: Self-adjusting reference electrode for minimal human intervention.
Customizable Test Protocols: Preloaded templates for lithium-ion, solid-state, and sodium-ion batteries.
3D Visualization Software: Real-time 3D mapping of ionic diffusion pathways and interface resistance.
Accessories Included
High-Sensitivity Probe Kit:
Platinum-iridium electrodes (2mm/5mm/10mm diameters).
Non-conductive ceramic sample holder.
Software Suite:
License key forSolidAnalyzer Pro(Windows/macOS/Linux).
1-year free access to cloud analytics platform.
Safety & Maintenance:
Anti-static gloves (3 pairs).
Calibration fluid (100mL, ISO 17025 certified).
Cleaning kit (lint-free wipes, alcohol solution).
Portability:
Reinforced aluminum carrying case with custom foam inserts.
Universal power cord (6 ft, detachable).
Technical Parameters
| Parameter | Specification |
|---|---|
| Ionic Conductivity Range | 10⁻⁸ S/cm to 10⁻² S/cm |
| Frequency Range | 10⁻³ Hz – 10 MHz |
| AC Amplitude | 1 mV – 1 V (adjustable) |
| Measurement Time | 0.5 – 600 seconds (user-definable) |
| Data Resolution | 24-bit ADC, 16 million data points per test |
| Power Supply | 100-240V AC, 50/60Hz (universal adapter) |
| Dimensions | 420mm (W) × 350mm (D) × 180mm (H) |
| Weight | 12.5 kg (net) / 15 kg (gross) |
