FPC Flex Durability Test device
Standard
ASTM F392
Product features
1. the stepper motor drive, high-precision positioning, low noise, can be used for a long time
2. program-controlled origin reset, no need to hand the fixture to the original position
3. the touch screen display controller for program input
4. the test Angle, speed, test times, and motor return to the origin can be set, automatic counting, product bending to the broken line can not be powered on, and can automatically stop operation
Technical parameters
1. Test station :1
2. test Angle: 10-180 degrees (touch screen digital setting)
3. test speed :10-120 times/min (touch screen digital setting; Stepper motor 60 times limit speed; Servo motor maximum limit speed of 120 times)
4. test stroke: 15-100mm (manual adjustable)
5. the test fixture maximum width and opening width :80mm
6. Test fixture: a set of lower end moving fixture and upper end moving fixture
7. the number of test counter :0——999999 times (touch screen digital can be preset, reach the number and product break automatically stop)
8. test function: touch screen set Angle, times, speed, etc., with a unique conduction function, disconnect automatically stop counting function, automatically find the origin and other functions
9. machine size (L×W×H) :450×380×700mm
10. machine weight: about 45kg
11. Working power supply :AC220V, 50HZ
