Floor Caster Wear Test meter
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Meet the standard:
GB/T 11982.2.
GB/T 4085.
BS/EN 425.
ISO 4918-2009
ASTM D6962
BS EN 425-2002
BS EN 985-2001
ISO 10581-2011
ANSI-NALFA-LF-01-2008.3.6 / ANSI-NALFA-LF-01-2011
Application:
The chair casters that can be moved and adjusted are controlled by the floor covering castor wear resistance tester. The resilient floor and laminated floor covering are placed on the test bench. The castor is started by the castor floor testing machine and acted on the resilient floor and laminated floor covering placed on the test bench. Stop automatically after the specified test time or number and take off the sample to see its change!
Technical parameters:
Host size: Length 1500mm* Width 1700mm*1620mm
Floor replacement base: 1350mm*1350mm(square, adjustable within this range)
Rotary diameter: 950mm
Total load load weight: 0-1500 lb (Note: 1 lb =0.4536 kg)
Rotary lifting distance: 400mm
Rotation speed adjustment range: 0-60 RPM, platform speed: (19±1)r/min, rotation (180±10)S after the platform stops and remains stationary (5±2)S, and then reverse operation.
Turntable counting range:
Turntable tooling card number: 3
Wheel: Caster wheel diameter: ￠50±2mm, width 23±3mm, crank distance: 32±2mm
Wheel hardness: Shore A(95±5)mm
Distance from caster to platform: (198±1)mm
The distance between the three casters is: (130±1)mm, the spacing is 120°, and the installation distance between any two casters is: (225±5)mm
