Respirator Fit Test meter
PortaCount Respirator Fit Tester:
Qinsun assesses the overall integrity of masks by performing an aerosol leak test utilizing the PortaCount Respirator Fit Tester as a particle detector. While under conditions of negative pressure and constant flow.
The mask is tested on a full headform with an enhanced bladder seal system to provide a tight seal for most CBRN gas mask and commercial respirator types and sizes. Testing masks on Qinsun’s full headform configuration allows for use of the mask’s head harness, mimicking a real-life application and providing more accurate test results.
The PortaCount Pro+ Fit Tester eliminates the guesswork associated with tedious and error-prone qualitative fit test methods. Rather than depending on a person’s chemical sensitivity or cooperation during a qualitative fit test, the PortaCount Pro+ Fit Tester measures actual fit.
Standard：
ISO 16975:3-2017
Features&Benefits:
Separate tests for overall mask integrity (Protection Factor), exhalation valve and drink tube
Integrated aerosol wand pinpoints leak locations, allowing for immediate evaluation and repair
Full headform configuration allows for use of the mask’s head harness, mimicking real-life application and providing more accurate test results.
Single head form with an enhanced bladder seal system creates a tight seal for most gas mask and full face respirator types and sizes.
Easy-to-read display with an intuitive step-by-step test sequence allows for minimal operator training
IncludedItems:
HEPA Filter Canister (x2)
Drink Tube Sampling Hose
DT & EV Bypass Hose
Emery Oil (500 ml)
PortaCount Fit Tester Interface Cable (for Models 8030/8038 only)
MITA Computer Cable
USB to Serial Converter
MITA Communicator Software CD
Quick Start Guide
Self Check Components Reference Card
