Fabric Vertical combustion tester
Product details：
fabric flame retardant performance test machine is mainly used to determine the textile flame, smoldering and carbonization tendencies. Suitable for flame-retardant woven fabrics, knitted fabrics, coated products, quilted products.
Scope of application:
fabric flame retardant performance test machine is mainly used to determine the textile flame, smoldering and carbonization tendencies. Suitable for flame-retardant woven fabrics, knitted fabrics, coated products, quilted products.
Main technical indicators:
1. Timing range 0.1s ~ 999.9s
2. Can be carried out vertical method, horizontal method, 45 ° A method, 45 ° Appendix A method, small 45 °, quilted products such as the determination of flame retardant properties.
3. Timing accuracy of 0.1s
4. Test flame height: adjustable
5. Burning box outer box size: 650mm × 650mm × 860mm
6. Burning box inside the box size: 600mm × 640mm × 740mm
7. Automatic output of exhaust fan power supply AC220V 3A
8. Power: AC220V ± 10% 50Hz
9. Power: 40W (excluding exhaust fan)
10. Net weight: 40Kg
Standards :
GB / T5455. FZ / 01028. GB / T14645. GB / T14644. FZ / T81005 and so on.
Features:
1. Stainless steel test box, surface drawing, with glass observation window;
2. Stainless steel support frame;
3. Stainless steel specimen frame;
4. Flame height adjustable (rotor flowmeter adjustment or burner adjustment);
5. The use of special aluminum panels;
6. With imported watches, metal keys;
7. A variety of different samples can be used interchangeably;
8. With commissioning dedicated air supply, with special conversion connector;
9. Inside the box is equipped with high temperature fire protection device tube.
