Laboratory tribology research equipment

Whats/App: +86 156 1874 6768

Web: standard-groups.com

Standards

GB/T 6040-2008 Test Method for Wear Resistance of Metal Surfaces

GB/T 17657-2022 Test Methods of Evaluating the Properties of Wood-Based Panels and Surface-Finished Panels (including abrasion and scratch tests)

ISO 20502 Fine Ceramics and Coatings — Scratch and Wear Testing

ASTM D3702 Test Method for Wear Rate of Materials Using a Rotating Drum Apparatus

ASTM D1894 Test Method for Static and Kinetic Coefficients of Friction of Plastic Film and Sheeting

JIS K 7317:2022 Plastics — Film and Sheeting — Determination of Coefficient of Friction

JIS L 0849 Testing Methods for Abrasion Resistance of Plastic Products

Parameters

ParameterSpecification
Sliding speed 5 mm/min – 6000 mm/min
Drive motor AC servo motor
Drive mechanism Rack and pinion
Sliding distance 1 – 100 mm
Motion mode – single Stops automatically after preset distance
Motion mode – reciprocating Reciprocating motion at set distance (up to 9.999.999 cycles)
Measurement range 0 – 1000 gf
Safety device Overload protection
Operating environment 0 – 50 °C, ≤85% RH, non-condensing
Power supply AC 100 V, 50/60 Hz
Dimensions W 475 × D 450 × H 475 mm (excluding protrusions)

Features

Load transducer positioned directly above the measurement point, eliminating unnecessary mechanisms and enabling direct friction force measurement

Optimized structural design minimizes response delay and setup-induced measurement errors

Orthogonal arrangement between worktable sliding direction and mechanical arm, eliminating load variation between forward and return strokes

Significantly improved repeatability and reliability of wear test results

Standard large pop-up acrylic safety cover allows observation during testing

Optional sealed enclosure configuration supports testing under controlled environmental or temperature conditions

Accessories

(1) Standard accessory set supplied with the machine

(2) Safety acrylic cover

(3) Operating documentation

Test Procedures

Secure the test specimen firmly on the worktable.

Select the appropriate test mode (single or reciprocating).

Set the sliding speed, distance, and load parameters according to the test standard.

Ensure the safety cover is properly positioned.

Start the test and monitor friction force and wear behavior during operation.

Stop the test automatically or manually upon completion.

Evaluate wear and friction results based on the applicable standard.
