Automotive Interior Materials Droplet Characteristics Tester
Производитель: Шанхайская компания Qianshi Precision Electromechanical Technology Co., Ltd
Все товары поставщика
Все товары поставщика
Automotive Interior Materials Droplet Characteristics Tester - Automotive Interior - standard
Standards:
1. 1995L0028-EN-01.01.2007-002.001-25 ( ANNEX V) Measurement method of melting properties. 2. NF P92-505 Dripping test with electrical radiator, used for melting materials. 3. EU 95/28/EC European parliament and of the council of 24 October 1995 relating to the burning behavior of materials used in the interior construction of certain categories of motor vehicle.
Applications:
It’s used to evaluate the melt dripping and burning performance for hot melt materials under the main heat source.
Product Information:
Introduction
Automotive interior materials droplet characteristics tester determine the materials’ droplet properties according to ECE R118 Appendix 7. This mechanical and electrical control tester is suitable for measuring the melting state of automotive interior materials in the specified radiation heat radiation.
Technical Parameter
Technical Parameter
| Items | Parameters |
| Power output of radiation heat source | 500W |
| Radiating surface of radiation heat source | Transparent glass plate, Φ (100 ± 5) mm |
| Sample support: | Φ118mm stainless steel ring with φ0.70mm, 2.10mm mesh stainless steel mesh in it. |
| residue container | Inner diameter 118mm, depth 12mm |
| Sample size | 70×70(mm), The thickness is no more than 13 mm |
| Distancefrom residue container to the sample rack | 300mm |
| The range of heat flux meter | 10W/cm2 |
| working power supply | AC220V, 50Hz, ≤1000W |
| The distance from the surface of the specimen to the surface of the radiation source | 30mm |
| Dimension | (Wide) 1120mm×(Depth)520mm×(Height)1250mm, vent hole Φ 100mm |
