Shoelace Abrasion Tester
Application:
This shoelace abrasion tester is used for shoelace against standard eyelet abrasion testing, or eyelet against standard shoelace abrasion testing. This tester is suitable for all kinds of shoelace and eyelet.
Principle：
Let shoelace cross the eyelet clamped on the fiber board, make the shoelace and eyelet form into 90 degree, make the fiber board and shoelace form into 45 degree. Then straining reciprocated the shoelace under the standard tension by eyelet. While the shoelace is damaged, stop the testing.
parameters：
Position：6 positions
Weights：455g ± 5g , 6pcs
Control method：Touch-screen control, 0~999,999
Standard eyelet：Brass, Inner diameter: 4.5mm
Fiberboard：25×25mm, Inner diameter 5.0 ± 0.2mm
Movable stroke：76 ±2 mm
Test speed：100±5cpm
Power supply：1∮AC 220V 50/60HZ
Dimensions（W×D×H）：57x58x1025px
Weight(approx.)：60 kg(excluding weight)
Standards:
SATRA TM93
