High temperature Robot protective clothing
Product advantages：
Flame retarda，High temper，Anti splash，High strength;
Design advantage:
Digital remote design,No field measurement required,Short supply cycle,High precision design,Only 2D & 3D digital analog, on-site video and pipeline trend are required.;
Application industry:
Metalworking,Smelting industry,Automobile,Sheet metal,Steel plant,Spare parts,Glass manufactory;
User pain point:
Existing Problems:Strong heat source,High heat radiation,Metal splash,High heat contact;
User loss:Robot aging,Equipment failure,Decreased quality of work,High maintenance cost;
Product Introduction:
It is made of high quality coated or impregnated composite materials with high temperature resistance, high strength and wear resistance, and adopts single or double layer material structure.
The product can play the role of heat radiation resistance and Spatter Resistance of high temperature molten metal for a long time under the high temperature environment of different grades at 200-1000 C.
It is mainly used in high temperature operation fields such as steelmaking, casting, forging and die manufacturing.
Material parameters:
Imported High Temperature Resistant Coating Materials
Through independent research and development and import, we have developed a variety of high temperature resistant coating materials. The base cloth is a high temperature resistant material with a duration of 0 seconds. It has good anti-twist and flexural performance and can meet the repetitive work of the robot at high frequencies without damage. Advanced coating technology, good heat reflection, long service life in high temperature environment.
Flame retardant nylon buckle
The flame retardant properties of the buckle and burr both reach grade B1 and have good tear resistance.
Flame retardant elastic band
It has good flame retardancy, high strength and elongation ratio of more than 1:2.5. It is not easy to fatigue under the action of external forces for a long time. Flame-retardant sewing thread: The suture is made of aramid 1414 fiber. It has high strength and good toughness. The limiting oxygen index is more than 28. It can effectively enhance the sutur
| Weight (g/m²) | After-flame Time (s) | After-glow Time (s) | After-glow Length (mm) | Anti-twist and Bending Performance | Tear Strength (N) | Breaking Strength (N) |
| 483.8 | 0 | 0.9 | 33 | 0 | 105 | 2100 |
| 660.5 | 0 | 1.6 | 32 | 2 | 276 | 2100 |
| 517.3 | 0 | 2 | 18 | 0 | 117 | 2100 |
Product details:
Accordion fold:Setting the organ pleats at the position where the robot has a large range of motion is helpful for the protective clothing to match the rotation range of the robot through self expansion.
Conical outlet:A conical structure is added at the back of the base to facilitate the pulling out of the pipeline from the inside of the protective clothing.
Pipeline suspension buckle:A pipeline hanging buckle is added at the lower end of the arm to facilitate the fixation of the pipeline.
Multiple elastic bands:The lower part and the main part are provided with multi-channel elastic belt, which is not only conducive to the fixation of protective clothing, but also fully meets the robot's motion space.
Protective effect:
Protection function:Insulating radiation,Isolate metal splash,Instantaneous stro;
Product value:Extending Service,Reduce shutdown,Reducing Mainten;
