Robot thermostatic protective clothing
Product advantages：
Heat-resisting，Cold-resistant，Ventilation，Dustproof;
Design advantage:
Digital remote design,No field measurement required,Short supply cycle,High precision design,Only 2D & 3D digital analog, on-site video and pipeline trend are required.;
Product Introduction:
It is composed of protective clothing, air supply device and ventilation pipe. It is applicable in the environment of - 40 —— 70 ℃。
Through the air supply device, the air in the micro environment of the protective clothing is continuously extracted, and the air with the temperature range of 10-40 ℃ is transported in, so as to maintain the constant micro environment temperature.
It is mainly used in artificial climate chamber to simulate extreme high and low temperature experimental environment and other extreme harsh environment.
Material parameters:
Imported high temperature resistant coating materials：
The material is cold resistant and heat-resistant, with the B1 level of fire-retardant performance; good bending and torsion resistance, good flexibility in harsh environment, not easy to wear; excellent mechanical properties, tear strength and breaking strength far greater than the general functional materials, with long service life.
Flame retardant elastic belt：
It has good flame retardancy, high strength, elongation ratio over 1:2.5, and is not easy to produce fatigue under the long-term action of external force.
Ventilating duct：
Good low temperature flexibility, wear resistance, surface resistivity less than 10 ^ 9 Ω, no pollution.
| Material Number | Weight (g/m²) | After-flame Time (s) | After-glow Time (s) | After-glow Length (mm) | Anti-twist and Bending Performance | Tear Strength (N) | Breaking Strength (N) |
| CY-T02 | 483.8 | 0 | 0.9 | 33 | Grade 0 | 105 | 2100 |
| CY-HR02 | 660.5 | 0 | 1.6 | 32 | Grade 2 | 276 | 2100 |
Application industry：
Cold storage，Low temperatur..,Pharmaceutical,Metalworking,Smelting industry,Spare parts;
User pain point:
Existing Problems:Extreme low temperature,Extreme high temperature,Lubricant solidification,Motor overheating;
User loss:Robot stop,Equipment failure,Motor damage,Line down;
Product details:
Radial elastic structure:Reserve operation space and avoid excessive expansion of protective clothing after inflation.
Motor loading port:The motor is protected separately to avoid falling or interference during the robot movement.
Air supply duct:After heat insulation treatment, the performance is stable under extreme temperature environment.
Bottom clamp fixing:The protective clothing is fixed on the robot by the double closing mode of elastic belt and clamp to prevent the exchange of internal and external gas.
