5kn 10kn 20kn 30kn 50kn 100kn Universal Material Tensile Tester
Applicable Industries
Fast Delivery Parts Of Universal Testing Machine,Tensile Compression Testing Machine,Universal Testing Equipment can test various materials (both finished and semi-finished products )of tensile strength ,compressive strength and elongation ,can do stripping ,tear strength ,flexural ,compression test and etc. It can connect up to the computer and display or printout the test times ,test value ,max. value ,etc .Also it can make various report forms according to the requirements .
Fast Delivery Parts Of Universal Testing Machine,Tensile Compression Testing Machine,Universal Testing Equipment is widely used in all kinds of hardware, metal, rubber and plastics, footwear, leather, clothing, textiles, insulators, wires, cables, terminals and other types of materials, testing, tensile, tear, peel,compression, bending, shear, three-point bending ... and other physical test performance.
Technical parameters
| Model | XB-OTS-600 |
| Max capacity | 5.10.20.50.100.200.250kgf 500kgf 2T 10T can be setting |
| Induction method : | Precision load cell (sensor) |
| Max. Load Capacity: | 5000kg |
| Force Resolution/Accuracy: | ± 0.5% |
| Accuracy class : | 0.5 |
| Resolution: | 1/1.000.000 |
| Test width | 400mm(Standard specifications special specifications can be customized) |
| Stroke Resolution: | 0.01mm |
| Machine Dimension(W*D*H) | 800×530×1600mm (L*W*H) orCustomized |
| Weight: | About 65kg |
| Power : | 1 phase 220V 50Hz |
| Packing | Standard Export plywood case |
| Displacement Control: | Displacement encoder count with four frequency technology So that the displacement of four times the resolution can up to 0.0005mm |
Forcesystem:servo drives +Servo motor +precision ball screw drive
Control system:Mechanical transmission +TM2101 +Pulse Command and Control System control
Measurement and Control System :TM2101 and control system; master controller uses the most advanced 32-bit ARM processor in the 21st century, the processing speed of the Pentium-class common computer standards, compared to the traditional 8yuan SCM control system overall performance greatly improved, faster operation, control accuracy higher
Obtain data:The key components are used America's most stable and ultra-precision 24 yuan AD, sampling rate of up to 2000 times /sec, can capture the power of instantaneous change process, the entire file, regardless of the resolution of up to 1.000.000 indexing
Software functions
1. Use windows workingplatform, set all parameter with dialog forms and operate easy;
2. Using asingle screen operation, do not need to change the screen;
3. Have simplified Chinese, traditional Chinese and English three languages,switch conveniently;
4. Plan test sheet mode freely;
5. Test data can be directly appeared in the screen;
6. Compare multiple curve data through translation or contrast ways;
7.With many units of measurement, the metric system and british system can switch;
8.Have automatic calibration function;
9.Have user-defined test method function
10.Have test data arithmetic analysis function
11. Have the function of automatic magnification, to achieve the most appropriate size of graphics
Corresponding Standard:
ASTM D903.F2258.GB/T 2790/2791/2792. CNS-11888.JIS K6854.GB/T 6329.BS EN 14410-2003.YY/T 0729.GOST 21751 and other standards.
Advantage
Ø 24 hours online
Ø 35 years experiences
Ø Sample chamber of each model
Ø Best price, fast delivery
Ø OEM,ODM
Ø Oversea offices
Ø Own import and export business license
ØISO,CE,UL,ASTM,DIN,EN,GB,BS,JIS,ANSI,TAPPI,AATCC,IEC,VDE
Customer Support Services
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via or internet
Ø On-site diagnosis and repair/online diagnosis and repair
Send product request
Other supplier products
 |
Automated Reaction Heat Meter | Standards GB 51283 GB/T 22232 GB/T 17802 SN/T 3078.1 Product Features 1. It offers three calorimetry methods: heat - flow, power - compensati... |
 |
Electric bicycle lighting device testing machine | Meet the standard: EN 15194 ISO 4210 UL 2849 ECE R50 StVZO Scope of application: Public, inspection, law, accident investigation, fire emergenc... |
 |
Water Leak Detector | Product Description GB/T 21619-2008 Test Methods for Dangerous Goods Flammable Solids Emitting Flammable Gases in Contact with Water, GB 19521.4-2... |
 |
