Epoxy polyester powder coating
Product model
GA, SF, FX, etc.
Product characteristics
The coating has good decorative properties, good adhesion and excellent mechanical properties.
Product application
Used for surface coating of refrigerators, household appliances, medical equipment, lighting, steel furniture, aluminum products and mechanical products.
Quality index
Standard number：Q/JSQ13-2006
| No. | Item | Index |
|---|---|---|
| 1 | Powder appearance | Powder, uniform color and no organic impurities |
| 2 | Sieve residue (125μm), % | 0, or negotiable |
| 3 | Coverage (film thickness 60-80um, flat spray), m²/kg | 7-10 |
| 4 | Film color and appearance | Meet the standard color plate and its color difference range |
| 5 | Flexibility, mm | Flat, ≤2; Semi-gloss, ≤5; Matt, ≤5 |
| 6 | Gloss, unit value | Flat, ≥85; Semi-gloss, 20-40; Matt, ≤10 |
| 7 | Adhesion, grade | ≤1 |
| 8 | Impact resistance, cm | ≥40 |
| 9 | Pencil hardness,H | ≥2 |
| 10 | Moisture and heat resistance (500h), grade | ≤1 |
| 11 | Salt spray resistance (800h), grade | ≤1 |
Construction reference
Construction method: spraying, voltage 50~100kv, air pressure 0.5~1.5kg/cm², spraying distance 150~300mm, coating thickness 60~80um, curing temperature 180℃/15min or 200℃10/min.
Construction instructions
The workpiece should be pre-treated before spraying to thoroughly remove surface contaminants. The compressed air should be oil-free and water-free and the oil-water separator should be checked frequently for normal operation. The working chuck should be of appropriate size and cleaned regularly to maintain good connection with the grounding transmission part. The powder feeder, powder gun and recycling system should be free of pollution and should not be mixed with powder coatings of different manufacturers or models, otherwise it will affect the appearance of the final coating. The temperature in the oven should be uniform, and the temperature difference of each part should not be greater than ±5℃ to reduce color difference. The recycled powder coating must be sieved and then mixed with new powder in the specified proportion. Dust should be avoided in the construction site to avoid affecting the appearance of the coating.
Packaging specifications
20kg/carton
Storage instructions
The product is sealed and stored in a ventilated place indoors at room temperature (<35℃). The storage period is one year from the date of completion of production. Expired products can still be used after passing the inspection.
Quality statement
The information and data provided in this manual are only used as our company’s suggestions for customers to refer to when selecting products. Although our company strives to ensure the accuracy of the information and data provided, in actual applications, many factors such as substrates, construction conditions, and use environment are beyond our control. Therefore, our company can only be responsible for the quality commitment of the relevant products themselves, and is not responsible for other aspects.
