Automotive Components Powder Coatings MT-A200 Series/powder coating with production traceability

Product Overview:

Epoxy polyester powder coating series designed for automobile engine blocks, suspension systems, filters, springs and other parts.

Coating characteristics:

-Good adhesion

-Good mechanical properties

-Excellent corrosion resistance

Application:

Suitable for various types of engines, suspension parts, filters and other automobile parts.

Application parameters:

Curing time: 180℃~200℃×10~15 minutesSpraying method: high voltage electrostatic spraying 60~80KVRecommended film thickness: 60~150um

Physical properties:

Project Instrument Judgment standard Test standard
Pencil hardness Pencil hardness tester ≥1H ASTM D 3363

GB/T 6739

Impact resistance Impact tester 50kg.cm(8mm diameter)
2.5Nm (16mm diameter)
(20mm diameter)
GB/T 1732
ASTMD2794
ISO 6272
Bending resistance Bending tester ≤2mm
(cylindrical shaft)
Conical shaft bending
Cylindrical shaft
GB/T 6742
ASTM D 1737
ISO 1519
Adhesion Hundred grid test Grade 0 GB/T 9286
ISO 2409
ASTM D 3359
Cupping Cupping tester ≥6mm GB/T 9753
ISO 1520
Salt spray resistance NSS salt spray ≥500H,Wb≤2mm GB/T 1771
ASTM B-117
ISO 7253
Moisture and heat resistance Constant temperature and humidity chamber ≥1000H slight gloss loss GB/T 1740
ISO 6270

The above tests are all conducted on 0.8mm degreased and rusted cold-rolled steel plates, with a coating thickness of 60-80um. The performance indicators of the coating will vary slightly with the gloss.

Environmental protection requirements:This product does not contain arsenic, selenium, lead, hexavalent chromium, mercury, antimony, cadmium, and other heavy metals, and fully complies with RoHS2.0 environmental protection requirements.

Note:We will provide complete powder coating consultation and application customization solutions based on the actual needs of each customer. The test indicators mentioned in this report are all laboratory test data for reference only and are not intended as performance commitments for product applications. The results may vary depending on environmental factors and other conditions.
