Accelerated Weather Tester(Xenon)丨 Accelerated Weather Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features and Benefits
1.Equipped with high-pressure xenon lamps, accurately reproduce the full spectrum of natural sunlight, including ultraviolet wavelength range of about 300-400nm.
2.In addition to light, the temperature is in a wide range ofambientto 100 ° C, the humidity is 50%-98% RH, and the spray volume and spray interval can be adjusted.
3.By enhancing the xenon lamp light intensity, 35~150w/㎡, greatly accelerate the aging rate of materials, greatly shorten the test cycle.
4.Flat shelf holderand rotatingholdersare optional, and theworkroomsize and test chamber performance can be customized according to your needs.
Specifications
|
Model |
STD XL-S-750 |
|
Internal Dimension (mm) |
950*950*850 mm |
|
Overall Dimension (mm) |
1400*1400*1950 mm |
|
Specimen Holder Size(mm) |
95*200 |
|
Specimen Capacity |
42pcs |
|
Chamber Type |
Rotating Holder |
|
Irradiation Source |
1 piece of 4500w water-cooled xenon arc lamp |
|
Irradiance Range |
35~150 W/㎡ |
|
Bandwidth Measurement |
300nm~400nm (340nm or 420nm) |
|
Chamber Temperature Range |
Ambient ～ 100 ℃ ±2℃ |
|
Black Panel Temperature |
BPT 35 ～ 85 ℃ ±2℃ |
|
Humidity Range |
50% ~ 98% RH |
|
Humidity Deviation |
± 5% RH |
|
Water Spray Cycle |
1~9999H59M (Adjustable) |
|
Controller |
Programmable color LCD touch screen controller |
|
Water supply system |
Automatic water supply, Water purification system |
|
Radiometer |
UV Radiometer, Tolerance: ±5% |
|
Cooling System |
Mechanical compression refrigeration system |
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
