Accelerated Weather Tester(Xenon)丨 Accelerated Weather Tester

Features and Benefits

1.Equipped with high-pressure xenon lamps, accurately reproduce the full spectrum of natural sunlight, including ultraviolet wavelength range of about 300-400nm.

2.In addition to light, the temperature is in a wide range ofambientto 100 ° C, the humidity is 50%-98% RH, and the spray volume and spray interval can be adjusted.

3.By enhancing the xenon lamp light intensity, 35~150w/㎡, greatly accelerate the aging rate of materials, greatly shorten the test cycle.

4.Flat shelf holderand rotatingholdersare optional, and theworkroomsize and test chamber performance can be customized according to your needs.

Specifications

Model

STD XL-S-750

Internal Dimension (mm)

950*950*850 mm

Overall Dimension (mm)

1400*1400*1950 mm

Specimen Holder Size(mm)

95*200

Specimen Capacity

42pcs

Chamber Type

Rotating Holder

Irradiation Source

1 piece of 4500w water-cooled xenon arc lamp

Irradiance Range

35~150 W/㎡

Bandwidth Measurement

300nm~400nm (340nm or 420nm)

Chamber Temperature Range

Ambient ~ 100 ℃ ±2℃

Black Panel Temperature

BPT 35 ~ 85 ℃ ±2℃

Humidity Range

50% ~ 98% RH

Humidity Deviation

± 5% RH

Water Spray Cycle

1~9999H59M (Adjustable)

Controller

Programmable color LCD touch screen controller

Water supply system

Automatic water supply, Water purification system

Radiometer

UV Radiometer, Tolerance: ±5%

Cooling System

Mechanical compression refrigeration system

Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
