Protective Clothing Liquid Static Pressure Tester

The Protective Clothing Liquid Static Pressure Tester is designed to evaluate the liquid penetration resistance of breathable protective clothing materials. It measures the ability of fabrics to resist the passage of corrosive liquids such as acids and bases under static pressure. This instrument is essential for testing chemical protective clothing to ensure wearer safety in industrial, laboratory, or hazardous environments.

Application

The instrument is suitable for testing liquid penetration resistance of protective clothing in the following industries and products:

(1) Chemical Industry: acid-proof and alkali-resistant protective suits — assessment of static liquid pressure resistance

(2) Medical and Laboratory Safety: lab coats, gowns, and aprons — verification of barrier performance against corrosive fluids

(3) Industrial Safety: industrial overalls, protective gloves, and aprons — liquid penetration testing for workplace safety

(4) Research and Development: development of new protective textiles, optimization of chemical resistance properties

(5) Quality Control Laboratories: production inspection of chemical protective clothing to ensure compliance with standards

(6) Certification and Regulatory Testing: third-party laboratories performing safety certification tests for protective materials

Standards

The instrument is compliant with the following standards, including related international standards:

(1) GB 24540-2009 – Acid and alkali resistant protective clothing — Liquid static pressure resistance test

(2) LFY-252 – Chinese standard for chemical protective clothing anti-seepage testing

(3) ISO 6530:2010 – Textiles — Protection against liquid chemicals — Determination of resistance of protective clothing materials to penetration by liquids

(4) EN 368:2017 – Protective clothing — Test method for resistance to penetration by liquids under hydrostatic pressure

(5) ASTM F903-18 – Standard Test Method for Resistance of Materials Used in Protective Clothing to Penetration by Liquids

Features

(1) Accurately measures static liquid pressure resistance of chemical protective fabrics

(2) Simulates real-life conditions of liquid exposure on protective clothing

(3) Adjustable liquid column pressure with continuous rising rate control

(4) Suitable for acids, alkalis, and other corrosive test liquids

(5) Provides quantitative measurement of fabric barrier performance

(6) Easy-to-read display for recording maximum liquid column height at first leaks

(7) Compact and durable design for laboratory and production floor use

Technical Parameters

ItemSpecification
Test Solution Acid/base solutions, e.g., 80% concentrated H2SO4 with varying concentrations
Rising Rate of Liquid (60 ± 3) cm/min
Maximum Liquid Column 150 mmH2O
Test Range 0 ~ 150 mmH2SO4 (80%)
Pressure Measurement Static pressure under atmospheric pressure (101.325 kPa)
Sample Measurement Resistance recorded at first three leaks
