Fiber Thermal Shrinkage Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Application
This tester is ideal for thermal shrinkage testing of single chemical fibers in production and quality control processes. Its high-precision measurement and automated data output streamline testing in chemical fiber manufacturing, textile production, fiber inspection labs, and research institutes. The compact design and imaging technology make it efficient for routine testing while ensuring accuracy and stability.
Standards
FZ/T 50004-1991: Test method for shrinkage in hot air of polyester staple fibers
Feature
(1) Digital imaging technology for automatic length measurement and shrinkage calculation.
(2) Compact instrument structure, suitable for laboratories with limited space.
(3) Fast and accurate testing process with low measurement error.
(4) Automatic data display and printout of results.
(5) Low failure rate and stable long-term operation.
(6) Easy to operate, minimal training required.
(7) Measures coefficient of variation to ensure fiber quality consistency.
Parameters
| Item | Parameters |
|---|---|
| Measuring range of thermal shrinkage | 0–25% |
| Precision | ±0.01 mm |
| Error of thermal shrinkage | ≤ ±0.1% |
| Gauge between upper and lower clamp | 20 mm ±1 mm |
| Number of fibers on sample cylinder | 35 |
| Power supply | 220V ±10% |
| Weight | 20 kg |
| Size (L×W×H) | 450 × 300 × 360 mm |
