Fully Automatic Dual-Plate Thermal Conductivity Tester (Guarded Hot Plate Method)
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Fully Automatic Dual-Plate Thermal Conductivity Tester (Guarded Hot Plate Method) is a precision instrument designed for thermal conductivity measurement of homogeneous and heterogeneous board materials. Based on unidirectional steady-state heat transfer principles, the instrument measures heat flux through the sample, the temperature difference between the upper and lower surfaces, and the sample thickness to calculate thermal conductivity.
Thetesteris fully computer-controlled and automates all testing and data processing, ensuring high accuracy and reproducibility. It is suitable for both solid boards and loose, granular, or soft materials when used with appropriate sample fixtures.
Application
This testeris suitable for testing the thermal conductivity of:
Plastics, rubber, glass, and fiber boards
Polystyrene foam (EPS), extruded polystyrene foam (XPS), polyurethane rigid foam
Foamed concrete, hollow glass, wood boards
Various insulation materials
Granular, loose, or soft materials (with optional fixtures)
Typical applications include:
Quality inspection of insulation and construction materials
R&D in thermal performance of polymer and foam materials
Academic research in thermal properties of solid and granular samples
Industrial production control for plastics, foams, and composite boards
Standards
The instrument complies with the following international and national standards:
GB/T 10294-2008 – Determination of Steady-State Thermal Resistance and Related Properties of Insulating Materials
GB/T 3399-1982 – Test Method of Thermal Conductivity for Plastics by Guarded Hot Plate Method
GB/T 10801.1-2002 – Measurement of Thermal Conductivity for Polyurethane Rigid Foam in Thermal Insulation
GB/T 10801.2-2002 – Measurement of Thermal Conductivity for Extruded Polystyrene Foam (XPS)
GB/T 3139-2005 – Test Method of Thermal Conductivity for Fiber Reinforced Plastics
GB/T 17794-2008 – Flexible Foam Rubber and Plastic Thermal Insulation Products
Parameters
| Item | Specification |
|---|---|
| Thermal conductivity range | 0.001–3.000 W/m·K |
| Measurement accuracy | ±2% |
| Repeatability | ±1% |
| Hot plate temperature range | Room temperature–150 °C (standard); optional up to 300 °C |
| Hot plate resolution | 0.01 °C |
| Cold plate temperature range | 0–60 °C (standard); optional -5–60 °C |
| Cold plate resolution | 0.01 °C |
| Sample thickness | 0–100 mm; resolution 0.001 mm; automatic measurement |
| Applied pressure | 0–500 N; resolution 0.1 N |
| Sample size | 300×300×(5–50) mm (standard); custom sizes available |
| Automation | Fully computer-controlled testing and data processing |
| Test duration | 60 minutes |
| Power supply | 220 V / 50 Hz; 500 W |
Features
Online temperature calibration: Unique technology allows fast, accurate calibration, improving accuracy by over 3 times.
Reduced testing time: Full testing completed in approximately 60 minutes.
Wide measurement range: Thermal conductivity 0.001–3.000 W/m·K.
Automatic thickness measurement: Computer-controlled, minimizing human error.
Automatic pressure control: Accurate, reproducible testing under varying pressures.
Versatile measurement: Supports solid boards and, with optional accessories, granular and loose materials.
Fully automated system: From measurement to data analysis and report output.
Accessories
Main instrument
Analysis software (Chinese & English versions)
HX-1005 precision low-temperature constant temperature water bath (0.01 °C accuracy)
Desktop computer (user-selected)
Calibration reference sample
Test Procedures
Prepare the sample according to size and thickness specifications. For loose or granular materials, use the optional sample fixture.
Place the sample between the hot and cold plates.
Set hot and cold plate temperatures via software.
Apply desired pressure using the computer-controlled automatic system.
Start the measurement; the system records temperature gradients and sample thickness automatically.
Wait for the completion of testing (approx. 60 minutes).
Software calculates thermal conductivity and generates data reports.
Maintenance Information
Keep hot and cold plates clean and free from residues.
Periodically calibrate using reference samples.
Inspect the pressure system and thickness sensors to ensure proper operation.
Maintain a stable laboratory environment to reduce measurement errors.
Ensure proper operation of the water bath for consistent cold plate temperature.
