100-V2 steam generator performance tester

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

The 100-V2 Steam Generator is designed for automotive thermal shock testing, capable of generating precise steam conditions required by major OEM thermal shock specifications. It provides controllable steam flow and pressure for repeatable testing of automotive components under thermal stress.

Application

(1) Automotive Thermal Shock Testing: Simulates rapid temperature changes on vehicle components using controlled steam injection.

(2) OEM Compliance Testing: Meets Ford, GM, and FCA thermal shock specifications for component validation.

(3) R&D and Quality Control: Evaluates thermal resistance and durability of automotive parts during design and production.

(4) Material and Component Verification: Supports verification of seals, coatings, and heat-sensitive parts under thermal stress.

Technical Parameters

ParameterSpecification
Model STD-100-V2
Water Flow Rate 2.7 ± 0.1 L/min
Steam Dynamic Pressure 37.9 ± 1.9 kPa
Tubular Nozzle Inner diameter 12.5 ± 0.3 mm, length ≥100 mm, non-corrosive material
Burner Type Adjustable gas/electric
Hose Compatibility High temperature/high pressure steam hoses
Dynamic Head Clamp STD-DHF-1
Measurement Distance 25 mm from nozzle
Measurement Tube Bore 4.7 mm
Power Supply AC 220V / 50Hz (standard)
Operating Environment Laboratory/Automotive test bench
