Ring-on-Block Friction and Wear Tester (Model 2M)
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Ring-on-Block Friction and Wear Tester (Model 2M) is a specialized instrument for evaluating the sliding friction and wear performance of materials and surface coatings. The tester utilizes a standard ring-on-block (shaft-bearing) friction pair to accurately measure friction coefficient, wear volume, and wear resistance under varying contact pressures and rotational speeds. The testing process is computer-controlled, ensuring stable data acquisition and high measurement accuracy. The instrument is suitable for research laboratories and industrial quality control.
Application
Sliding friction and wear performance evaluation of metallic materials.
Wear testing of non-metallic materials (plastics, nylon, composites).
Investigation of surface coatings, platings, and surface treatments.
Performance comparison of bearing materials, journal-bearing materials, and friction pairs.
Research on material tribology under dry and lubricated conditions.
Material quality testing in research institutions, universities, and industrial laboratories.
Standards
GB/T 3960-2016 Plastics – Determination of Sliding Wear Properties
GB/T 3960-1983 Plastics – Determination of Sliding Wear Properties (equivalent previous version)
ASTM G77 Ring-on-Block Friction and Wear Test
DIN 50324 General Friction and Wear Testing
ISO 7148 Sliding Friction and Wear Testing (relevant sections)
Parameters
| Parameter | Specification |
|---|---|
| Test Load Range | 100–1000 g (weight loading) |
| Automatic Loading Range | 10–200 N |
| Friction Ring Size | Diameter 40 mm, Width 10 mm |
| Spindle Speed Range | 5–2000 r/min, continuously adjustable |
| Friction Coefficient Measurement Accuracy | 0.2% F.S |
| Control Method | Computer automatic control |
| Data Acquisition | Real-time measurement of friction coefficient and wear volume |
| Power Supply | 210–235 V, 50–60 Hz |
| Power Consumption | 2500 W |
| Workbench Size | 1800 × 750 × 800 mm (user-supplied) |
Features
Standard ring-on-block friction pair ensures high repeatability of test results.
Supports both weight loading and automatic loading, covering a wide load range.
Continuously adjustable spindle speed allows simulation of different operating conditions.
High-precision friction coefficient measurement for comparative research and quality control.
Computer-controlled testing process with real-time data display and storage.
User-friendly interface, easy maintenance, suitable for long-term stable operation.
