Spray Aerosol Ignition Distance Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
Spray Aerosol Ignition Distance Tester is a specialized device for measuring the ignition distance of spray aerosols, designed to assess fire hazards associated with aerosol products. It is suitable for spray aerosol products with a spray distance of 15 cm or greater.
Standards
United Nations Recommendations on the Transport of Dangerous Goods, Manual of Tests and Criteria 31.4 Ignition Distance Test for Spray Aerosols
GB/T 21630-2008 “Dangerous Goods - Ignition Distance Test Method for Spray Aerosols”
GAT 536 “Classification and Test Methods for Fire Hazard of Flammable and Explosive Dangerous Goods”
NY/T 1860 “Guidelines for Determining Physicochemical Properties of Pesticides” Part 27: Flammability of Aerosols
Features
1) Embedded processor with Windows CE operating system.
2) 8-inch LCD touchscreen for real-time display of test status.
3) Integrated “Standard Mode” and “Custom Mode” operation.
4) Automatic spray dispensing with can holder that automatically positions cans upright or inverted.
5) Nanosecond-level photosensitive sensor detection module automatically monitors spray combustion.
6) Hybrid stepper motor drive with optical encoder ensures precise positioning of measurement points.
7) Ignition gun source produces a blue, non-luminous flame 4-5 cm high, with adjustable flame height.
8) Fully automated testing process requires no manual intervention, supporting parameter settings, data storage, and report viewing.
9) Dedicated fire-resistant bellows cover effectively prevents equipment contamination.
10) Equipped with a temperature and humidity module for real-time monitoring of test environment conditions.
11) Combustion gas source housed in a dedicated sealed chamber to ensure gas supply safety.
12) Streamlined testing process operates fully automatically after initiation, eliminating the need for personnel supervision and ensuring operator safety.
Parameters
| Item | Specifications |
|---|---|
| Operating Environment | (-5 ~ 45)°C, <95% RH |
| Detection Method | Near-infrared detection |
| Spectral Response Range | 760 ~ 1100nm (infrared band) |
| Spectral Response Frequency | 5000Hz |
| Ambient Temperature Measurement Range | (-10 ~ +60)°C |
| Ambient Temperature Measurement Accuracy | ±0.5°C |
| Ambient Humidity Measurement Range | (5 ~ 95)% RH |
| Ambient Humidity Measurement Accuracy | ±5.0% RH |
| Combustion Detection Response Time | ≤6ms |
| Combustion Detection Distance | (15 ~ 90)cm |
| Positioning Accuracy | ±1mm |
| Timing Accuracy | ±0.01s |
| Minimum Press Hold Time | 5s |
| Ignition Method | Gas igniter |
| Aerosol Can Positioning | Automatic rotation of aerosol can body |
| Compatible Spray Can Dimensions | Height (120 ~ 400)mm, Diameter (30 ~ 80)mm |
Accessories
Main Control Unit (1 set): Integrated chassis with 8-inch touchscreen.
Motorized Positioning Track (1 set): For precise movement of the igniter.
Aerosol Can Clamping System (1 set): Compatible with standard can sizes, featuring automatic inversion.
Near-Infrared Sensor Module (1 set): High-speed combustion detection unit.
Gas Ignition Source (1 unit): Adjustable gas burner for standard flame generation.
Fireproof Bellows (1 set): To protect the internal drive components.
Water Bath (Optional): For sample pre-conditioning at $25^{circ}text{C}$.
在线联系供应商
Other supplier products
 |
Filter Media Tester G505，ISO 11057 air filtration media performance tester | Whats/App: +86 156 1874 6768 Web: standard-groups.com The Filter Media Dynamic Filtration Performance Tester is primarily used to assess the filt... |
 |
Air Permeability Tester STD-F8 ，ASTM D737 air exchange rate testing machine | Whats/App: +86 156 1874 6768 Web: standard-groups.com The Air Permeability Tester is a high-precision instrument designed to measure the breathab... |
 |
Dry Sand Rubber Wheel Wear Tester | Standard ASTM G65 JBT_7705 Applicable standards Dry and wet abrasive wear testing machines usually need to follow certain standards and specifi... |
 |
Multifunctional Rapid Thermal Conductivity Tester (TPS & Hot Disk Method)，Benchtop High-Precision Material Thermal Conductivity Tester | Whats/App: +86 156 1874 6768 Web: standard-groups.com Multifunctional Rapid Thermal Conductivity Tester (Integrated Unit) is a high-precision ins... |
 |
Atlas material testing technology | Whats/App: +86 156 1874 6768 Web: standard-groups.com Applications The SUGA S80 Carbon Arc Weathering Tester utilizes eight sunlight carbon arc ... |
