Mattress Rollator ASTM F1566
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Mattress Rollator is used for durability and performance evaluation of the following products:
Innerspring mattresses
Foam mattresses (polyurethane foam, memory foam)
Latex mattresses
Hybrid mattresses (spring + foam or latex structures)
Children’s and adult mattresses
Mattress prototypes during design validation
Production quality control and type testing in mattress manufacturing
Standards
The Mattress Rollator complies with or references the following standards:
ASTM F1566 Section 6 – Mattress Hardness Rating
ASTM F1566 Section 7 – Mattress Durability Testing
GB/T 26706 – General Technical Requirements for Mattresses (related clauses reference)
Parameters
| Parameter | Unit | Specification |
|---|---|---|
| Test Station | — | Single station |
| Roller Type | — | Hexagonal roller |
| Roller Mass | lb (kg) | 240 lb (approx. 109 kg) |
| Test Cycles | — | 100,000 cycles (200,000 reciprocating strokes) |
| Simulated Service Life | — | Approx. 10 years |
| Test Speed | cycles/min | Adjustable, up to 20 |
| Stroke Length | — | Programmable |
| Applicable Mattress Size | — | Single to king size |
| Control System | — | PLC with touchscreen interface |
| Power Failure Protection | — | Roller auto-lift with cycle memory |
| Equipment Dimensions | in | 101 × 113 × 82 |
| Equipment Weight | lb | Approx. 3,000 |
| Shipping Weight | lb | Approx. 3,300 |
| Power Supply | — | 480 V, three-phase (240 V optional) |
Features
240 lb hexagonal hardwood roller mounted on precision ball bearings
Roller assembly laterally balanced for uniform load distribution
Vertical and lateral free-floating roller design, independent of cylinder hysteresis
Adjustable roller lateral position to accommodate different mattress widths
Programmable stroke with consistent starting position
Variable-speed motor control for flexible test cycle adjustment
PLC-controlled cycle counting with automatic stop at test completion
Automatic roller retraction and data retention during power outages
Lower limit protection to stop operation in case of excessive specimen wear
Tool-free mattress platform adjustment using lever-operated mechanisms
Sealed polyurethane wheels and stainless steel tracks for low maintenance
Independent floor-mounted control panel with emergency stop function
