Velcro Fatigue Tester | ASTM ISO Testing Machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The hook and loop fastener fatigue tester/hook and loop tape fatigue strength tester is suitable for testing the adhesive strength of hook and loop fasteners (hook and loop tapes) after repeated peeling and bonding actions, and for evaluating whether they meet the standard requirements.
Standards
DIN : Textile touch-and-close fasteners – Requirements for fabric adhesive zippers.
GB/T 3903.21-2008: Footwear – Test method for fastening tape shear strength before/after repeated opening/closing.
ISO 22776-2004: Footwear – Test method for attachments (fastening shear strength after repeated closures).
JSB 39-1993: Military-grade nylon fastening tape specifications.
DIN EN 12242-1999: Contact locks – Determination of peel strength.
GB/T 23315-2009: General fastening tape standards.
Advantages
Fully Automated Operation: Eliminates manual intervention with automatic counting, auto-stop upon completion, and audible alerts for seamless workflow.
Rapid Sample Exchange: Innovative winding-tensioning fixture design allows quick changes, reducing downtime and boosting lab efficiency.
Versatile Testing: Accommodates fastening tapes of all sizes, from apparel to industrial applications.
Real-World Simulation: Mimics repeated bonding/peeling cycles to evaluate long-term adhesion durability.
Portable & Space-Saving: Compact yet robust construction enables easy relocation between testing facilities.
Data-Driven Results: Post-test dynamometer integration provides precise average adhesive force measurements.
Features
Dual-Roller System: Separate rollers for hook (male) and loop (female) surfaces ensure consistent contact pressure during cycling.
Adjustable Test Cycles: Programmable up to 999.999 repetitions to meet diverse standard requirements.
Heavy-Duty Wheel: Applies calibrated pressure to simulate high-stress use cases (e.g., footwear, automotive interiors).
Ergonomic Controls: Intuitive interface with LCD display for real-time cycle tracking and error diagnostics.
Safety First: Overload protection and emergency stop function guarantee operator safety.
Modular Design: Fixtures and rollers are interchangeable for compatibility with various fastening tape geometries.
Parameters
| Item | Specification |
|---|---|
| Roller diameter | Upper roller: φ162.5mm, Lower roller: φ160mm |
| Roller width | Generally 70mm or 80mm |
| Rolling speed | 60rpm/min (or 60±5r/min) |
| Reversing time | 30s |
| Load | 5kg |
| Counter | LCD display, 0~999.999 cycles |
| Horsepower | AC 1/8HP dual-frequency motor |
| Power supply | AC220V, 50Hz |
| Dimensions & Weight | Vary by model |
