Flex Durability Tester
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Flex Durability Tester is suitable for testing the rub resistance of various flexible films, composite films, and coated films. It is also known as a rub tester or film rub tester. It can simulate the rubbing, folding, and pressure damage that films experience during production, processing, and transportation. After the rub test, the material's rub resistance is evaluated by detecting changes in the number of pinholes or the barrier properties before and after the test, providing quantitative data for packaging design and practical applications.
Applications
- Packaging Industry: The rubbing resistance tester is widely used in the packaging industry. It helps enterprises detect the anti - rubbing ability of packaging materials, ensuring that products will not be damaged by external rubbing during transportation and storage. For example, food packaging and pharmaceutical packaging have extremely high requirements for rubbing resistance. Only through strict testing can the integrity of the packaging be guaranteed, thus safeguarding the quality and safety of the products.
- Material R & D: In the field of material research and development, the rubbing resistance tester is an indispensable tool. Experimenters can use it to study the performance characteristics of different materials, optimize material formulations and processes, and develop more durable and reliable new materials.
- Optimized Design: The test results of the rubbing resistance tester can provide quantitative data for packaging designers, helping them understand the performance of materials under specific conditions, thereby optimizing packaging designs. For example, designers can adjust the thickness, structure, or coating of packaging materials according to the test results to improve the durability and reliability of the packaging.
- Quality Control: Manufacturers can use the rubbing resistance tester to ensure that the quality of packaging materials meets relevant standards and regulatory requirements, thereby enhancing the market competitiveness of products and reducing safety risks caused by packaging problems.
Standards
ASTM F392: Test Method for the Flexural Resistance of Flexible Barrier Layer Materials
YY/T 0681.12: Test Methods for Sterile Medical Device Packaging - Part 12: Soft Barrier Materials - Resistance to Stretch
GB/T 41347-2022: Test Method for the Stretch Resistance of Flexible Packaging Materials
Features
7-inch touchscreen operation for convenient and quick setting of test parameters
Password login for four-level management access
Four sample stations easily enable combined tests under different conditions
Servo motor control ensures precise stroke positioning, further guaranteeing the accuracy of test results
Equipped with a mini printer for convenient data printing at any time
Brand-name drive motors offer strong environmental adaptability, stability, and durability
Precision-machined motion mechanisms ensure low-noise operation
Program limit protection and an emergency stop button provide both hardware and software protection for the instrument.
Technical Parameters
| Technical Parameter | Specification |
|---|---|
| Rubbing Frequency | Usually adjustable, such as 45 times per minute, etc., used to simulate the rubbing frequencies that packaging materials may encounter in actual use. |
| Number of Rubbing Times | Usually, there are multiple modes available, such as Mode A (2700 times), Mode B (900 times), Mode C (270 times), etc., to meet different testing requirements. Some devices also support arbitrary settings of the number of rubbing times for more flexible testing. |
| Specimen Size | Determined according to testing standards or actual requirements, such as 120×30mm, etc. The selection of specimen size should ensure that it can fully reflect the rubbing resistance performance of the material. |
| Control System | An advanced control system enables automated operation, reducing human-induced errors. Meanwhile, the control system can also be used to set and control test conditions, such as the number of rubbing times and speed. |
| Monitoring System | It includes force sensors and other detection devices, used to monitor the state changes of specimens in real-time during the test. This is crucial for analyzing the durability of materials and identifying potential defects. |
| Safety Devices | To ensure the safety of operators, the rubbing resistance tester is usually equipped with various safety protection measures, such as emergency stop buttons and overload protection. |
