Plastic Scratch Test machine
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Plastic Scratch Test Machine is a precision testing instrument designed to evaluate the scratch resistance of plastics, films, coatings, and automotive interior and exterior decorative materials. By simulating controlled scratch conditions, it provides accurate, repeatable, and quantifiable data on surface durability, aiding in product development, quality control, and comparative performance analysis.
Application
The Plastic Scratch Test Machine is widely used for:
Assessing the scratch resistance of polymer films and plastic sheets
Evaluating coating systems and paint layers for durability
Testing automotive interior and exterior decorative materials
Quality control in R&D laboratories and manufacturing facilities
Specific testing product: Plastic Scratch Test Machine
Standards
The instrument is designed to comply with major international and national standards:
ASTM D7027‑05 – Method for evaluating scratch resistance of polymer coatings
ASTM G171 – Method for determining scratch hardness of materials
ISO 19252 – Scratch durability testing of coating systems
GB/T 23989‑2009 – Determination of scratch resistance of coatings
GB/T 1768‑2006 – Method for measuring abrasion resistance of paint films
Parameters
| Item | Details |
|---|---|
| Dimensions (approx.) | 800 × 400 × 730 mm |
| Power Supply | AC 100V, Max 60W |
| Operating Temperature & Humidity | 10–40°C / 30–70% RH, non-condensing |
| Testing Method | Increasing load method |
| Scratch Direction | Left to right |
| Detector | Force sensor |
| Vertical Load | 1–200 N |
| Horizontal Load | 200 N |
| Accuracy (Full Scale) | ±0.5% or better |
| Scratch Distance | 400 mm |
| Scratch Speed | 1 mm/sec – 400 mm/sec |
| Number of Measurements | Approx. 1000 |
Optional Configurations:
Scratch tip radii: 0.5 mm, 0.75 mm, 1 mm (customizable)
Load weights: 1 N, 2 N, 5 N, 10 N, 20 N, 50 N (customizable)
Test spacing: 100–400 mm ±0.5 mm
