IEC Certified Rice Cooker Durability Testing Equipment
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
(1) IEC 60335-1 Household and similar electrical appliances – General requirements
(2) IEC 60335-2 Series for specific household cooking appliances
(3) ISO 16750 Mechanical load and durability testing principles
(4) GB/T 4706.1 Safety of household and similar electrical appliances
Features
Simulates real lid opening and closing actions through automated mechanical operation
Pneumatic and stepper motor drive ensures stable and repeatable movement
PLC and touchscreen control provide intuitive operation and clear status display
Dual-layer password protection prevents unauthorized parameter changes
Automatic counting, alarm, and shutdown improve test safety and efficiency
Robust frame structure offers stability, durability, and long service life
Technical Parameters
| Item | Specification |
|---|---|
| Main Application | For life and durability testing of rice cooker lid opening/closing |
| Applicable Objects | Conventional rice cookers, electric pressure cookers, and similar products |
| Number of Test Stations | Single station |
| Counting Method | Touch screen display |
| Specific Functional & Technical Parameters | |
| Basic Function | The equipment drives the fixture via a stepper motor to simulate frequent opening/closing of the pressure cooker lid, achieving simulation and aging durability testing of mechanical structure, sealing ring, heating plate, etc. |
| Electronic Control System | Adopts PLC + touch screen control system, stable operation and easy maintenance; human-machine interface with menu operation for easy use; all parameter settings and status displays are completed on the touch screen; dual-layer password protection prevents unauthorized operation. |
| Alarm Function | Automatic counting, preset test times, alarm prompt and shutdown when the set times are reached; includes fault alarm and count alarm functions. |
| Safety Protection | Equipped with leakage protection, undervoltage protection and other safety devices. |
| Efficiency/Cycle | Related to the actual working time of the product, each control action time is adjustable. |
| Main Configuration | Electric control cabinet made of stainless steel; stepper motor-driven fixture for opening/closing action; frame with chrome-plated steel plate surface for stability, reliability, aesthetics and durability. |
| Power Supply | Control power: AC220V/50Hz |
| Color | Main body: bright chrome silver |
| Equipment Power | Control system: ≤1.5Kw; product power calculated separately |
| Dimensions | ≤800×800×1500 mm (LWH) |
Accessoriess
(1) Standard lid opening and closing test fixture
(2) Pneumatic push rod assembly
(3) PLC control unit
(4) Touchscreen control panel
(5) Operation and maintenance manual
