Hydraulic fluid precision filtration device
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
Filtration of hydraulic lubrication system during refueling.
● Bypass filtration of hydraulic lubrication system during operation.
● Circulation filtration of hydraulic lubrication system before operation.
● Hydraulic lubrication system oil is not filtered and pumped out by the pump of the equipment itself.
(Note: This machine is not applicable to flammable and explosive media such as fuel oil.)
Standards
NAS 1638 : Cleanliness Requirements for Hydraulic Fluids
ISO 4406: 2021 Hydraulic fluid power — Fluids — Method for coding the level of contamination by solid particles
GJB 420A-2006 : Classification of Solid Particle Contamination in Hydraulic Systems and Components
GB/T 14039-2002 – Hydraulic Transmission: Oil contamination control and monitoring
GB/T 18854-2015 – Hydraulic Transmission: Determination of solid particle contamination levels
Technical Parameters
| Technical Parameters | Specifications |
|---|---|
| Working Pressure | 0.6MPa |
| Differential Pressure for Alarm | 0.2MPa |
| Flow Rate | 50±5L/min |
| Medium | ≤160mm/s (20℃) |
| Accuracy | 5μm |
| Rated Power | 2.2KW |
| Power Supply Voltage | 3-phase 380V |
| Frequency | 50Hz |
| Operating temperature | 20℃ - 70℃ |
Accessoriess
1. Core Functional Components:
Dedicated gear pump (low noise, self-priming)
Multi-stage filtration system (including coarse filter and replaceable fine filter cartridges of different precision)
High-pressure pipeline and overflow protection device
Pressure gauge and differential pressure transmitter (for real-time monitoring of system pressure and filter cartridge contamination level)
2. Electrical and Control Components:
Control panel (including buttons and display screen)
Three-phase 380V power adapter
2.2KW rated power drive motor
3. Consumable Components:
Filter cartridges of different precision (matching 5μm and other precision requirements)
Seals (such as O-rings, pipeline gaskets, for leak prevention)
Sampling-related components (such as sampling bottles, pipeline connectors; some equipment comes with high-cleanliness sampling tools)
4. Auxiliary Components:
Casts (easy-to-move parts on the bottom of the equipment)
Instruction manual, certificate of conformity, and other documentation
