Gripping tester
Product introduction
This machine mainly aims at the ability of the product to withstand the pressure of
lead from the car when the product is packed in the warehouse or truck, train, etc., so as
to evaluate the damage of the product.
This machine adopts servo motor control, full computer operation, high-grade configuration.
Tests are customized according to ASTM D6055, U.S., SEARS, corporate standards, or
customer specified non-standard requirements.
Scope of application
Applicable to all product packaging testing and verification. The main test is that the
product packaging is subjected to horizontal pressure during transportation and storage
The deformation of the force and the protection ability of the packaging inside the
package, so as to improve the packaging design.
Technical parameter
Sample shape: parallelepiped transport package
Maximum test weight: 100kg
Clamping pressure: 400——3000Lb（adjustable） pressure can be applied on the
corresponding surface according to the handling diagram on the test sample
Clamping plate surface size: 1100x1100mm（L/W）
Test space size: 1000x1000x1000mm（length, width and height）
Clamping plate height adjustment: 0-1000mm can be set
Lifting speed: 10-500mm/mi adjustable
Clamping speed: 10-50mm/min adjustable
Splint expansion width: 200——2000mm
Transmission mode: Japan Panasonic servo motor （left and right clamps）
Base plate size: 2000x1900mm
Protection device: leakage protection limit device
Cleat requirements: Two gripper plates in the working state （2000 pounds） to ensure
smooth without deformation. The two splints are parallel to each other, and the splints are
vertical to the floor. The thickness of the splint shall not be less than 20mm
Force corrector: With force value display, used to correct the clamping pressure
Force accuracy: national standard 1.6 level
