Battery Slurry Resistance Tester
Standard
ASTM B193: Standard Test Method for Resistivity of Electrical Conductor Materials
ISO 18516: Conductive Coatings – Measurement of Resistivity
IEC 62660-3: Secondary Lithium-Ion Cells – Part 3: Safety Requirements
RoHS Compliance(Restriction of Hazardous Substances)
CE Certification(Conformité Européenne)
Product Advantages
Precision in Viscous Media
Sub-milliohm Sensitivity: Measures resistivity as low as 0.1 mΩ·cm for high-solids slurries.
Non-Contact Electrodes: Eliminates contamination risks with gap-sensing technology.
Rapid Process Integration
2-Second Test Cycle: High-speed sampling for inline production monitoring.
Auto-Cleaning System: Solvent-resistant nozzles prevent cross-contamination.
Intuitive Operation
7” HD Touchscreen: Glove-compatible interface with multilingual support (10 languages).
QR Code Data Export: Share test results instantly via smart scanning.
Industrial Robustness
Chemical-Resistant Body: 316L stainless steel enclosure with PTFE coating.
IP65 Rating: Withstands dust, splashes, and harsh cleaning agents.
Smart Connectivity
IoT Integration: Real-time data streaming to PLC/SCADA systems via OPC UA.
AI-Driven Diagnostics: Predicts slurry stability based on resistivity trends.
Product Features
Dynamic Temperature Control: Built-in Peltier module (-20°C to 80°C ±0.2°C accuracy).
Viscosity Compensation: Auto-adjusts measurements for slurries up to 10.000 cP.
Multi-Frequency Testing: Simultaneous DC and AC (1 Hz – 10 kHz) analysis.
Laser-Guided Sampling: Ensures consistent probe immersion depth (±0.05 mm).
Emergency Shutoff: Magnetic reed switch for immediate power cutoff.
Technical Parameters
| Parameter | Specification |
|---|---|
| Resistance Range | 0.1 mΩ – 200 Ω (auto-ranging) |
| Accuracy | ±0.2% of reading + 0.05 mΩ |
| Test Voltage | 10 mV – 10 V (programmable) |
| Sampling Rate | 10,000 points/second |
| Data Interface | Ethernet, USB 3.0, Wi-Fi 6, Bluetooth 5.2 |
| Power Supply | 100-240V AC, 50/60Hz (universal adapter) |
| Dimensions | 350mm (W) × 300mm (D) × 180mm (H) |
| Weight | 15 kg (net) / 18 kg (gross) |
Accessories Included
Slurry Testing Kit:
Platinum-iridium electrodes (10mm/20mm spacing).
Disposable sample cups (100mL, 500mL).
Software Suite:
License key forSlurryAnalyst Pro(Windows/macOS).
6-month free access to cloud-based SPC tools.
Calibration & Safety:
NIST-traceable standard resistor (10 mΩ, 100 mΩ, 1 Ω).
Chemical-resistant gloves (Class 0. 2 pairs).
Portability Case:
Waterproof Pelican case with custom foam inserts.
Shoulder strap and padlock eyelets.
Documentation:
Multilingual quick-start guide (printed + digital).
Compliance certificates for ASTM/ISO/CE standards
