Thermal cycle wet freezing testing machine
Standard
- IEC 61215: Terrestrial Photovoltaic (PV) Modules – Design Qualification and Type Approval
- UL 1073: Standard for Safety for Enclosures for Electrical Equipment
- ISO 16750-4: Road Vehicles – Environmental Conditions and Testing for Electrical and Electronic Equipment
- CE Certification(Conformité Européenne)
Product Advantages
- Extreme Environmental Simulation
- -40°C to +85°C Range: Replicates Arctic cold to desert heat in a single chamber.
- 98% RH Humidity Control: Tests condensation resistance for marine/tropical applications.
- Ultra-Stable Performance
- ±1°C Temperature Stability: Ensures consistent testing across 1,000+ cycles.
- ≤±2°C Uniformity: Patented airflow design eliminates hot/cold spots.
- Rapid Transient Response
- IEC 61215-Compliant Ramps: 10°C/min heating, 7°C/min cooling (customizable).
- Auto-Tuning PID: Adapts to payload changes in real-time.
- Energy Efficiency
- 40% Lower Power Consumption: Advanced insulation and heat recovery systems.
- ECO Mode: Auto-powers down during stabilization phases.
- Safety First
- Dual Overload Protection: Thermal cutout and current-limiting circuit breaker.
- Door Interlock System: Prevents accidental chamber access during testing.
Product Features
- Dual-Chamber Design: Isolated wet/dry zones for simultaneous multi-condition testing.
- 10” Touchscreen HMI: Preloaded IEC/UL test profiles with customizable hold times.
- Remote Monitoring: Wi-Fi/Ethernet connectivity with SMS/ alerts.
- Self-Diagnostics: Real-time sensor health checks and error logging.
- Glovebox Compatibility: Oxygen/moisture control for sensitive electronics testing.
Technical Parameters
| Parameter | Specification |
|---|---|
| Temperature Range | -40°C to +85°C (operational) |
| Temperature Fluctuation | ≤±1°C |
| Temperature Deviation | ≤±1°C (at steady state) |
| Temperature Uniformity | ≤±2°C (empty chamber) |
| Heating Rate | 10°C/min (typical, configurable) |
| Cooling Rate | 7°C/min (typical, configurable) |
| Humidity Range | 30%–98% RH (non-condensing) |
| Humidity Deviation | ±3% FS (at 85% RH ±2%, 90% RH ±2%) |
| Chamber Volume | 500L (standard), expandable to 1,500L |
| Power Supply | 380V/415V 3-phase, 50/60Hz |
| Dimensions | 1,200mm (W) × 1,800mm (D) × 2,000mm (H) |
| Weight | 800 kg (net) / 1,200 kg (gross) |
Accessories Included
- Testing Kit:
- 4x universal sample racks (adjustable for batteries/PV modules/PCBAs).
- 10x humidity sensor calibration capsules.
- Software Suite:
- License key forEnviroTest Pro(Windows/Linux).
- 1-year free access to cloud-based test report generator.
- Calibration & Safety:
- NIST-traceable temperature/humidity logger.
- Emergency eyewash station (portable).
- Maintenance Kit:
- Spare heating elements and refrigerant filters.
- Chamber cleaning solution (non-corrosive).
- Documentation:
- Multilingual quick-start guide (printed + digital).
- Compliance certificates for IEC/UL/ISO standards.
