Strength Tester for Lead - end of Photovoltaic Modules
Standard
IEC 61215-2:2016: Terrestrial Photovoltaic (PV) Modules – Test Requirements for Electrical and Mechanical Components
CE Certification(Conformité Européenne)
Product Advantages
IEC 61215-2 Compliance
2.000mm × 1.000mm Test Area: Accommodates full-size 72-cell modules and custom formats.
≤3% Measurement Accuracy: Ensures pass/fail determination per IEC’s tensile load requirements.
Ultra-Precise Control
0.1N Force Resolution: Captures micro-fractures before catastrophic failure.
Auto-Tare System: Compensates for fixture weight during low-force testing.
Automated Testing
Programmable Load Profiles: Simulates 10+ years of thermal cycling in 1.000 cycles.
AI-Powered Failure Detection: Real-time IV curve correlation for connector degradation.
Safety First
Emergency Shutoff: Dual redundant safety circuits with load cell override.
Overload Protection: 5 kN max force cutoff for delicate junction boxes.
Modular Design
Quick-Change Fixtures: Adapts to MC4. H4. and custom PV connectors.
Expandable Test Area: Custom sizes up to 3.0m × 2.0m for large-format modules.
Product Features
Motorized Tensile Stage: 0–500 mm/min adjustable speed with force-displacement graphing.
7” Touchscreen HMI: Preloaded IEC 61215-2 test sequences with auto-hold functions.
Dynamic Force Feedback: 0.1N resolution load cell with peak force memory.
Self-Calibrating System: Auto-linearity checks before each test.
Rust-Resistant Frame: 304 stainless steel construction with epoxy coating.
Technical Parameters
| Parameter | Specification |
|---|---|
| Test Area | 2.000mm (W) × 1.000mm (D) (customizable) |
| Force Range | 0–5.000N (5 kN capacity) |
| Force Resolution | 0.1N (10 gf) |
| Speed Accuracy | ±1% of setpoint |
| Power Supply | 220V AC, 50/60Hz (single-phase) |
| Dimensions | 2.200mm (W) × 1.200mm (D) × 1.800mm (H) |
| Weight | 250 kg (net) |
Accessories Included
Testing Kit:
10x PV Connector Fixtures (MC4/H4 compatible).
5x Calibration Grade Load Cells (10N–5.000N).
Software Suite:
License key forTensileTest Pro(Windows/Linux).
1-year free access to cloud-based fatigue analysis tools.
Calibration & Safety:
NIST-traceable force gauge.
Insulated gloves (Class 0. 3 pairs).
Maintenance Kit:
Spare drive belts and bearings.
Machine cleaning solution (non-corrosive).
Documentation:
Multilingual quick-start guide (printed + digital).
Compliance certificates for IEC/UL/ISO standards.
