Battery Electrode Resistance Tester
Standard
ASTM B193: Standard Test Method for Resistivity of Electrical Conductor Materials
ISO 18516: Conductive Coatings – Measurement of Resistivity
IEC 62660-1: Secondary Lithium-Ion Cells – Part 1: Performance Testing
RoHS Compliance(Restriction of Hazardous Substances)
CE Certification(Conformité Européenne)
Product Advantages
Ultra-Sensitive Detection
0.1 μΩ Resolution: Measures resistivity as low as 1 μΩ·cm for advanced anode/cathode materials.
Four-Point Probe Technology: Eliminates contact resistance errors for pristine data.
Rapid Material Characterization
3-Second Testing Cycle: High-throughput screening for production lines.
Auto-Mapping Function: Generates 2D resistivity heatmaps of entire electrode sheets.
User-Centric Design
12.1” Capacitive Touchscreen: Multi-touch gestures for zoom/pan on live data curves.
Voice-Guided Operation: Step-by-step instructions in 8 languages (English, Korean, German, etc.).
Industrial Durability
Corrosion-Resistant Chassis: 316L stainless steel body with IP54 dust/water resistance.
Vibration-Dampening Feet: Stable operation in noisy factory environments.
Smart Connectivity
IoT-Ready: Seamless integration with MES/ERP systems via MQTT protocol.
AI-Powered Analytics: Predicts battery cycle life based on resistivity trends.
Product Features
Non-Destructive Testing (NDT): Preserves electrode integrity with
Temperature Compensation: Built-in Peltier module (-10°C to 60°C ±0.5°C accuracy).
Dynamic Range Switching: Auto-adjusts between μΩ and mΩ ranges during testing.
Laser-Assisted Alignment: Guides operator for perfect probe placement on 50x50mm samples.
Emergency Power-Off: Dual redundant safety circuits with E-stop button.
Accessories Included
Four-Point Probe Head:
Tungsten carbide tips (0.5mm spacing) with gold-plated connectors.
Quick-release lever for rapid probe replacement.
Software Suite:
License key forResiMAP Pro(Windows/macOS/Linux).
1-year free access to cloud-based SPC (Statistical Process Control) tools.
Calibration & Safety:
NIST-traceable standard resistor (10 μΩ, 100 μΩ, 1 mΩ).
Insulated gloves (Class 00. 3 pairs).
Portability Kit:
Heavy-duty rolling case with TSA-approved locks.
Retractable handle and 8” all-terrain wheels.
Documentation:
Multilingual quick-start guide (printed + digital).
Compliance certificate portfolio (ASTM/ISO/CE).
Technical Parameters
| Parameter | Specification |
|---|---|
| Resistance Range | 1 μΩ – 200 mΩ (auto-ranging) |
| Accuracy | ±0.1% of reading + 0.05 μΩ |
| Test Current | 1 mA – 1 A (programmable) |
| Sampling Rate | 20.000 points/second |
| Data Interface | Ethernet, USB 3.0. RS-485. Wi-Fi 5 |
| Power Supply | 90-264V AC, 47-63Hz (universal adapter) |
| Dimensions | 480mm (W) × 420mm (D) × 220mm (H) |
| Weight | 28 kg (net) / 32 kg (gross) |
