Xenon Arc Chamber
Features and Benefits
1. According to different specimens, xenon aging test chamber has a variety of models to choose from; For flat specimens, rotating drum type xenon arc chamber is the best; for irregular samples, shelf type xenon arc chamber is suitable.
2.The xenon arc chamber is equipped with a water-cooled xenon arc lamp, which has high stability and good cooling performance.
3.The xenon arc test chamber has a variety of filters to choose from: Daylight Q, Daylight B/B, Window Q, Window B/B filters.
4.The xenon arc chamber can be used for color fastness testing, cracking, weathering, aging testing, and meets various light aging testing standards, such as ASTM, ISO, etc.
Specifications
|
Model |
STD XL-S-750 |
|
Internal Dimension (mm) |
950*950*850 mm |
|
Overall Dimension (mm) |
1400*1400*1950 mm |
|
Specimen Holder Size(mm) |
95*200 |
|
Specimen Capacity |
42pcs |
|
Chamber Type |
Rotating Holder |
|
Irradiation Source |
1 piece of 4500w water-cooled xenon arc lamp |
|
Irradiance Range |
35~150 W/㎡ |
|
Bandwidth Measurement |
300nm~400nm (340nm or 420nm) |
|
Chamber Temperature Range |
Ambient ～ 100 ℃ ±2℃ |
|
Black Panel Temperature |
BPT 35 ～ 85 ℃ ±2℃ |
|
Humidity Range |
50% ~ 98% RH |
|
Humidity Deviation |
± 5% RH |
|
Water Spray Cycle |
1~9999H59M (Adjustable) |
|
Controller |
Programmable color LCD touch screen controller |
|
Water supply system |
Automatic water supply, Water purification system |
|
Radiometer |
UV Radiometer, Tolerance: ±5% |
|
Cooling System |
Mechanical compression refrigeration system |
