PV Light Induced Degradation (LID) Testing Chamber

Applications

The Light Decay Test Chamber is designed as an indoor exposure system, primarily used for standard module and cell degradation testing, module hot spot testing, and module pre-treatment. Spectral matching, irradiance uniformity, and irradiance stability meet at least BBB-grade standards.

This system comprises a light source system, temperature control system, module support structure, light source control system, and irradiance monitoring system. Utilizing xenon lamps as the light source, the irradiance across the exposure surface can be steplessly adjusted between 400 and 1200 W/m².

Standards

IEC 61215: Terrestrial photovoltaic (PV) modules—Design qualification and type approval (Specifically the Light-Induced Degradation and Hot-spot tests).

IEC 60904-9: Photovoltaic devices—Part 9: Classification of solar simulator characteristics (Meeting BBB or higher standards).

GB/T 9535: Ground-based silicon solar photovoltaic modules—Design qualification and type approval.

IEC 61646: Thin-film terrestrial photovoltaic (PV) modules—Design qualification and type approval (Stabilization phases).

Features

1. Utilizes a xenon lamp as the light source, providing an irradiation area of 1m x 2m, with over-temperature power-off protection.

2. Records irradiance, chamber temperature, and provides both instantaneous irradiance and cumulative irradiation data.

3. Chamber employs air cooling, with internal temperature controllable within 20°C to 50°C.

Parameters

Category	Item	Specifications
1. Xenon Lamp Parameters	Dimensions	200*40mm
	Power	1800W
	Operating Voltage	180VAC
	Lamp Life	700h (with cumulative timing function for lamp tube)
2. Chamber Structure	Construction	Welded integral structure
	Outer Wall Material	Galvanized steel sheet (spray-painted)
	Inner Wall Material	SUS304 stainless steel sheet
	Insulation Material	Glass fiber or polyurethane foam material
	Accessories	Equipped with standard viewport: 1 multi-layer glass window (with work light)
3. Radiometer	Spectral Range	300 ~ 3000nm
	Irradiance Range	0 ~ 2000W/m²
	Annual Stability	2%
	Azimuth Response Error	5%
	Non-linearity	2%
	Temperature Error	2% (-10°C ~ 40°C)
4. Temperature	Sensor Type	PT100
	Measurement Range	-200 ~ 500°C
	Test Accuracy	±1°C
	Resolution	0.1°C
	Probe Diameter	Φ5mm
	Installation Method	Fixed with movable screws
	Probe Length	5cm
	Resistance Change	0.3851Ω/°C
	Lead Connection Method	Three-wire type
	Sleeve Material	Stainless steel 304

Accessories

1.High-Intensity Xenon Lamp Array: Core light source with a 700-hour rated lifespan and cumulative timer.

2.Slide-in Sample Carrier: Aluminum profile bracket with rollers for easy loading/unloading of heavy modules.

3.Calibrated Pyranometer: High-stability sensor for real-time irradiance monitoring.

4.Infrared Temperature Sensor: Non-contact monitoring to ensure the sample surface temperature stays within the $pm 10^{circ}text{C}$ control range.

5.Multi-layer Viewing Window: Standard observation port with specialized glass to protect against radiation while allowing visual inspection.

Test Procedures

1. Site: Level ground with good ventilation, free from flammable, explosive, or corrosive gases and dust. No strong electromagnetic radiation sources nearby. Adequate maintenance space around equipment.

2. Environmental Conditions:

Temperature: 5°C to 35°C

Relative Humidity: ≤85% RH

Atmospheric Pressure: 86–106 kPa

3. Power Supply:

AC 380V, three-phase four-wire + protective earth wire;

Voltage tolerance range: AC (1±10%) 380V

Allowable frequency fluctuation range: (1±1%) 50Hz

Protective earth grounding resistance must be less than 4Ω; TN-S or TT power supply system

Users must install an appropriately rated air or power circuit breaker at the installation site, dedicated exclusively to this equipment

4. Storage Environment Requirements:

When the equipment is not in operation, the ambient temperature must be maintained between +5°C and 35°C.

Other supplier products

	Floor Material Burning Performance Tester，Flooring Radiant Panel Tester by ISO 9239-1	Thefloor coverings flammability testeris used to tester a variety of flooring materials, such as: textile carpets, cork, wood, rubber and plastic f...
	Large Flame Flammability Tester	Introduction The Flame Flammability Tester is developed according to the NFPA 701 Method 2 and can be used for single or multi-layer fabrics. It&r...
	Motor Accessories Combustion Testing Machine, Fmvss 302，ISO 3795	Introduction: This machine is designed according to ISO3795 standards and relevant clauses. Apply to identify vehicles (cars, multipurpose passeng...
