Goggles Puncture Resistance Testing Machine
The safety goggle puncture resistance testing machine is a device used to test the puncture resistance of safety goggles against impact from sharp objects.
Application
It is to make a certain weight of sharp objects fall from the height specified in the standard and act on the surface of helmet or goggles, so as to determine the ability of helmet or goggles to resist penetration by sharp objects.
Standards
GB 811-2010:Helmets for motorcyclists
ECE R22.05:Uniform Provisions Concerning the Approval of Protective Helmets and Their Visors for Drivers and Passengers of Motor Cycles and Mopeds
EN1077:Helmets for alpine skiing and snowboarding
Parameters
| Item | Detail |
|---|---|
| Impact height | 1000mm ~ 3000mm |
| Impact hammer | 3kg, with a cone tip angle of 60 degrees |
| Head fixed frame | Has an adjustable device for rapid and convenient helmet installation |
| Conduit | Adopts high-strength aluminum tube anodic treatment, with a beautiful appearance |
| Hammer lifting method | Manual lifting |
| Impact hammer release device | Electromagnet release device |
| Total height of the instrument | About 5m |
| Voltage | 220V |
Accessoriess
Perforator (puncture cone)
Drop hammer (impact hammer)
Head fixation device (head mold support)
Guide tube
Electromagnetic release device, etc.
Test Procedures
Sample and Equipment Inspection: Confirm that the goggles to be tested are free of manufacturing defects and are properly installed on the corresponding size safety helmet/headgear according to the standard.
Parameter Setting: Select a matching head form, fix the helmet onto the head form, ensuring the goggles are at a natural wearing angle without extra stretching or compression.
Positioning the Punch: Manually adjust the punch position so that it is vertically aligned with the center area of the goggles, and the bottom of the punch is in contact with the surface of the goggles, leaving a space of at least 5mm above the head form.
Performing the Impact Test: Using a manual pull-type or automatic release device, allow the falling weight to drop freely from a set height, impacting the top of the punch, and transferring the impact force to the goggles through the punch.
Data Recording: Record data at the moment of impact using a high-speed camera or pressure sensor, such as the peak impact force and the deformation of the goggles, for subsequent analysis.
在线联系供应商
Other supplier products
 |
SUGA S80 Carbon Arc Weathering Tester | Applicable Standards The SUGA S80 adheres to globally recognized standards, including: ISO, AATCC, ASTM(e.g., ASTM G152. ASTM D822 for coatings) ... |
 |
Helmets Designated Protection Areas Tester | The helmet designated protection area testing device is a piece of equipment used to mark test points and lines on helmets, and is suitable for all... |
 |
Hydrogen Sulfide Corrosion Test Chamber | The Hydrogen Sulfide Corrosion Test Chamber is a precision environmental testing instrument designed to evaluate the corrosion resistance of metals... |
 |
Carpet Peel & Tuft Tester | Product Details For tufted carpets or traditional carpets, an important parameter is the retention performance of their tufts. Poor - quality car... |
 |
Adjustable guide wire friction tester equipment | Whats/App: +86 156 1874 6768 Web: standard-groups.com Application This tester is suitable for a wide range of medical devices and scenarios, inc... |
