Rubber Hose Outer Coating Wear Testing Machine ISO 6945
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Rubber Hose Outer Coating Wear Testing Machine is a precision laboratory and production testing instrument designed to evaluate the abrasion resistance of rubber and thermoplastic hose outer coatings. It is suitable for hoses reinforced with fabric or steel wire and featuring smooth, flat surfaces. By applying a controlled reciprocating motion with a defined vertical load, this machine simulates real-world wear conditions experienced by hydraulic, automotive, and industrial hoses, providing accurate and reproducible data for quality control, R&D, and material performance evaluation.
Applications
(1) Hydraulic hoses: Rubber hoses with smooth, flat outer coatings reinforced with fabric or steel wire.
(2) Industrial hoses: Air, water, and chemical hoses with similar outer coating structures.
(3) Automotive hoses: Brake lines, fuel lines, and coolant hoses.
(4) Testing laboratories: Quality control and research for abrasion resistance of hose coatings.
(5) Material evaluation: Suitable for rubber, thermoplastic, or composite hose cladding.
Standards
(1) GB/T 12721-2007 — Determination of abrasion resistance of rubber hose outer coating
(2) ISO 6945:1991 — Rubber hoses — Determination of abrasion resistance of cladding
(3) KS M ISO 6945-2013 — Determination of abrasion resistance of the outer coating of rubber hoses
(4) EN ISO 6945-1996 — Determination of abrasion resistance of rubber hose outer coatings
(5) DS/ISO 6945-1984 — Determination of wear resistance of rubber hose cladding
Features
(1) High reproducibility: Provides consistent and accurate abrasion testing of rubber hose outer coatings.
(2) Versatile mandrel sizes: Supports a wide range of shaft diameters to accommodate different hose types.
(3) Adjustable load: Vertical static pressure can be set according to the product standard or customized.
(4) Simulates real-world wear: Reciprocating motion reproduces the friction and wear that hoses experience in operation.
(5) Easy operation and setup: Simple installation of hose samples and abrasive tool ensures quick test preparation.
Technical Parameters
| Item | Specification |
|---|---|
| Reciprocating frequency | 1.25 Hz (45 RPM) |
| Cycle stroke | 200 mm |
| Loading static pressure | 50 N ± 0.5 N (customizable) |
| Mandrel length | 150 mm |
| Shaft diameters | 5, 8, 10, 13, 16, 19, 22, 25, 32, 38, 45, 51 mm (3 selectable, or customized) |
| Power supply | AC 220V, 50/60 Hz (typical) |
