Compression resistance tester for textiles
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
The G5 Compression Tester is suitable for:
Fibers and Textiles: Compression comfort testing of underwear, bedding, and apparel fabrics
Rubber and Foam Materials: Footwear soles, seat cushions, packaging materials
Bedding Products: Evaluation of compression and recovery of mattresses, pillows, and lumbar cushions
Consumer Electronics: Testing compression performance of touch buttons, soft housings, and cushioning pads
Medical Products: Assessment of compression characteristics of dressings, protective pads, and soft materials
Scientific Research: Studies on material compression mechanics, tactile comfort, and rebound performance
Standards
GB/T 6669-2011 — Test methods for compression properties of rubber, foam, and soft materials
ISO 3386-1/2 — Determination of compression properties of foam
ASTM D3574 — Standard test methods for flexible polyurethane foam
Technical Parameters
| Parameter | Specification |
|---|---|
| Dimensions / Weight | Tester: W170 × D220 × H460 mm / 13 kg Electronic Amplifier: W180 × D400 × H400 mm / 13 kg |
| Power Supply | AC 100V, max. power 20W |
| Measurement Environment | Temperature 20–30℃, Humidity 50–70% RH, non-condensing |
| Compression Load Testing | Differential transformer (ring-type load cell) |
| Compression Load Range | 100 gf, 200 gf, 500 gf, 1000 gf (switchable) |
| Compression Load Accuracy | ≤ ±0.5% full scale |
| Compression Deformation Measurement | Potentiometer |
| Maximum Compression Deformation | 20 mm |
| Deformation Accuracy | ≤ ±0.5% full scale |
| Compression Platen Area | 2 cm² (standard circular platen) |
| Compression Speed | Standard: 0.02 mm/sec High Sensitivity: 0.0067 mm/sec Adjustable |
| Sample Size | Square 2–10 cm |
Test Principle
The G5 Compression Tester measures the material response under localized pressure. A standard circular platen applies controlled compression to the sample. Load cells (differential transformers) measure applied force, while potentiometers record deformation. The device can calculate compression hardness, compression work, and recovery properties, providing quantitative analysis of tactile performance and material elasticity.
Operation Instructions
Prepare a sample (2–10 cm square, thickness as required).
Place the sample under the circular compression platen.
Select the desired load (100 gf–1000 gf) and compression speed (standard or high sensitivity).
Start the test; the instrument measures compression force, deformation, and recovery.
Record and analyze data to evaluate material compression performance.
Maintenance Information
Clean the compression platen before and after each test.
Inspect load cells and potentiometers for calibration and wear.
Avoid exposure to moisture or corrosive materials.
Store in a stable environment, avoiding vibration and direct sunlight.
