Digital TPP Calibration Equipment
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
(1) BS EN ISO 6942 – Protective clothing – Protection against heat and flame – Method of test for the determination of heat transfer on exposure to a heat source
(2) EN 366 – Protective clothing against heat and flame – Resistance of materials to contact heat
(3) EN 407 – Protective gloves against thermal risks (heat and/or fire)
(4) ISO 11612 – Protective clothing – Clothing to protect against heat and flame
(5) ASTM F1939 – Standard Test Method for Evaluation of Thermal Protective Performance of Materials for Clothing
(6) ASTM F2702 – Standard Test Method for Heat Transfer and Thermal Protective Performance of Flame Resistant Clothing Materials Using a Thermal Protective Performance Tester
(7) NFPA 1971 – Standard on Protective Ensembles for Structural Fire Fighting and Proximity Fire Fighting
(8) NFPA 2112 – Standard on Flame-Resistant Garments for Protection of Industrial Personnel Against Flash Fire
(9) GB 38543 – Technical Specification for Fire Protection of Workwear for Industrial Personnel
(10) GB/T 38306 – Test Method for Thermal Protective Performance of Flame Retardant Protective Clothing
Feature
Standard calorimeter mounting block.
PLC control system provides stable and fast testing performance.
Analysis software with user friendly interface is easy to use and installed Stoll curve model internally.
Compact structure design reduces the requirements of fume hood.
Evaluates the potential for skin burns associated with a fabric’s ability to block convective and
radiant heat penetration
Automatic test operation provides repeatable and precise results
Independently controlled radiant heat source and convective heat source
Supports up to three copper disk calorimeter sensor assemblies
Integrated air-cooled sensor stand quickly prepares calorimeter sensor for next test
Water-cooled shutter is pneumatically actuated for precise exposure control
Automatically predicts time to second degree burn, with results shown as a real-time numerical and graphical display of sample performance compared to the Empirical Performance Curve
Small and portable, the TPP test device fits in most standard fume hood
Technical Parameters
| Heat Flux Measurement Range | 0–167 kW/m² |
| Heat Flux Measurement Accuracy | ±2 kW/m² |
| Specimen Irradiated Size | ≥200mm*200mm,for testing flame-retardant protective clothing, fire-fighting suits and protective gloves |
| ConvectionHeatSource | 2Merkel lamps (Heat flux: up to 60 kW/m²; Radiant heat flux: up to 40 kW/m²) |
| Rotor Propane Gas Flowmeter | Provides precise, stable propane flow for the burner |
| Radiant Heat Source | 9pcs of500W infrared quartz lamps (proportional power controlfor0–30 kW/m²radiant heat flux) |
| ASTM F2703Copper Calorimeter | Accuracy±3% F.S.;Weight 1000±10 g |
| Copper Calorimeter Copper Plate | Imported Oxygen-Freesuperconductingcopper |
| Data Acquisition System Sampling Rate | ≥20samples/second |
| Environment | 15–35℃ |
| Fume Hood | Recommended internal dimensions ≥150×75×90 cm, including door height |
| Gas Source | Propane (Purity≥95%, equipped with pressure reducing valve - cylinder & outlet pressure controlled) |
| Compressed Air | Customer-supplied |
| Cooling Water Source | Tap water (inlet & outlet) or optional chiller |
| Power supply | Single phaseAC220V 50Hz |
| Dimension | 130×65×53cm (LXWXH) |
| Weight | Around 60kg |
Test Procedures
Sample Conditioning: Cut specimens according to standard requirements and pre-treat them under specified conditions (e.g., drying at 105°C).
Specimen Mounting: Secure the specimen in a 45-degree fixture, ensuring the surface is flat and wrinkle-free.
Thread Ignition Cord: Install marked cotton cord at the designated position on the specimen and attach the timing weight or sensor.
Flame Adjustment: Ignite the butane gas and precisely adjust the flame height to 16mm using the scale.
Ignition Initiation: Press the start button; the ignition burner automatically moves toward the specimen and ignites it (typically retracting after 1 second).
Data Reading: When the sample burns to the marked line and melts the cotton thread, the timer automatically stops. Record the displayed spread time.
Maintenance Information
Timely Carbon Removal: After each test, promptly clean carbon deposits and combustion residues from the burner and sample holder to prevent gas line blockage.
Gas Line Sealing: Periodically inspect gas source connection hoses with soapy water to ensure no gas leaks.
Sensor Cleaning: Maintain cleanliness of the flame-detection device to prevent ash ingress causing timing failure.
Environmental Ventilation: Conduct tests within a fume hood. Activate exhaust systems post-test to remove hazardous fumes.
