Textile far-infrared radiation temperature rise test instrument
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
Textile Far Infrared Radiation Temperature Rise Tester is used for various textiles including fibers, yarns, fabrics, nonwovens, and their products. It employs temperature rise testing to determine the far-infrared performance of textiles.
Standards
GB/T 30127-2013 ：“Textiles - Testing and Evaluation of Far-Infrared Properties” Clause 4.2 Test Method for Far-Infrared Radiation Temperature Rise
T/CAS 115.5-2021:Health Care Textiles — Part 5: Far Infrared
Features
1. Features an industrial-grade color touchscreen display and control system with an intuitive human-machine interface that is simple to use and enhances operational convenience.
2. Utilizes an automatic measurement mode, enabling one-touch initiation to automatically complete the testing process.
3. Incorporates high-precision sensors capable of rapid response and accurate measurement of current temperature.
Parameters
|
Parameter Item |
Parameter Value |
|
Specimen Holder |
500mm distance from radiation source to specimen surface |
|
Radiation Source |
Main wavelength 5μm~14μm, radiation power 150W |
|
Specimen Irradiation Area |
φ60~φ80mm |
|
Temperature Range & Accuracy |
15℃~50℃, ±0.1℃ precision, ≤1s response time |
|
Specimen Types |
|
Test Procedures
I. Power-Up and Setup
1. Connect Power:
Turn on the instrument's power switch to enter the setup interface.
2. Parameter Settings:
Irradiation Power: Typically set to 150W.
Test Duration: Generally 30 seconds.
Test Cycles: Set according to standard requirements, e.g., 5 cycles.
II. Sample Installation
1. Fixture Selection:
Thin Samples: Install thin-sample fixture and tighten the nut.
Thick Samples: Place directly onto the disk, aligning with the center.
2. Sample Placement:
Ensure the test line is positioned at the center point.
Place the sample face up and secure the edges with a ruler.
III. Test Procedure
1. Preheat: Click “Turn on Light” to preheat the instrument.
2. Start Test:
Click the test interface; timing starts for 30 seconds.
Observe temperature rise value, initial temperature, and final temperature.
Automatic Result Display: Data appears automatically upon test completion.
IV. Data Processing
Data Retrieval: Click Details to view test results.
Report Printing: Click Print to generate the test report.
在线联系供应商
Other supplier products
 |
Bag fastener magnetic buckle testing machine | Product Introduction: This machine is mainly used to test the durability of the finished magnetic buckle under the action of tension Implementati... |
 |
Custom impact abrasion resistance tester | Whats/App: +86 156 1874 6768 Web: standard-groups.com Application You use this tester to evaluate the abrasion resistance of motorcycle protecti... |
 |
