SPRINKLER TRUCK
With sprinkling water, dust removal, pesticide spraying, guardrail washing, water transport, emergency fire and other functions.
It is driven by the engine to drive the gearbox, and the force extractor installed on the gearbox drives the sprinkler pump, which generates the main power and sprays the liquid inside the tank through the pipe network. Self-priming height :≤7m, sprinkler width :≥20m, maximum range :≥28m;
Adjustable into column shape, range ≥28m; Can also be adjusted into fog, range ≥5m.
Water Tanker Truckcan be sprayed before and after spraying, the front is equipped with a duck-shaped nozzle or round head nozzle, the back is equipped with a cylindrical sprinkler nozzle or showerhead nozzle, and the rear has a working platform equipped with a high-pressure water cannon.
Tank production:blanking, automatic welding, head spinning forming, tank rolling forming and other production processes.
Tank material: made of high quality carbon steel plate. 304 stainless steel can also be used according to customer needs.
The tank volume has 4cbm6cbm8cbm10cbm12cbm15cbm20cbm and so on.
|
Item |
Description |
|
Chassis brand |
ISUZU brand |
|
Condition |
Brand new |
|
Drive type: |
6×4 |
|
Steering wheel |
Left hand drive |
|
Cab |
Four-point hydraulic suspension cab, |
|
Engine power(kw) |
ISUZU 6HK1-TCH ;300HP engine |
|
Fuel type |
Diesel |
|
Emission standard: |
Euro5 |
|
Transmission gear: |
RTD-11509C With QH50 Flange power take-off;9 gears, manual |
|
Tyre specification : |
|
|
Wheelbase(mm): |
4375+1400 mm |
|
Oil tank capacity: |
400L Aluminum alloy |
|
Axle |
|
|
Potable water body |
|
|
Tank capacity |
20000liters |
|
Tank material |
stainless steel 304/ Carbon steel sheet |
|
Pump |
Pump in pump out |
|
Other |
Pipes, valves,water outlet / Water Inlet, |
We are a professional Sanitation Truck Supplier, more details please contact us!
