Paper Crease Stiffness Tester
Product Introduction:
ZY-TDY300 microcomputer bending stiffness tester is used to measure the bending stiffness of paper and cardboard materials with low gram weight. It is used to evaluate the stiffness and resilience of flexible materials. It can set the vertical and horizontal direction, tension size, test speed and bending Angle of the sample according to the test requirements. Mainly used to measure all kinds of paper, cardboard, film, plastic, wire, metal sheet and other composite materials bending stiffness test, the measurement range is :0——1000g(0——10000mN) suitable for paper packaging printing industry and related scientific research institutions and quality inspection departments.
Compliance Standards:
ISO 5628 ISO 2493
TAPPI T489 TAPPI T556 JIS P 8125
Product Advantages:
Measures Key Stiffness Properties: Quantifies bending stiffness, a fundamental property for material performance evaluation. May also offer related "folding stiffness" measurements.
Versatile Material Testing: Applicable to a wide array of sheet materials, including paper, board, films, plastics, and thin metals.
High Accuracy and Resolution: Provides precise measurements with a high-accuracy sensor and fine resolution (0.01mN), enabling differentiation between similar materials.
Controllable Test Parameters: Offers flexibility in setting test direction, speed, bending angle, and spacing, allowing for customized and standard-compliant testing.
Multiple Measurement Modes: Includes different stiffness measurement modes, potentially including a mode related to folding or crease behavior ("stiffness/folding Wolf stiffness dual system").
User-Friendly Interface: Features a 7-inch touch screen or button interface for intuitive setup and operation.
Data Output and Reporting: Provides options for computer data linkage and includes an integrated thermal printer for immediate result documentation.
Technical parameters:
1. Sample size :38*(70——200)mm
2. Actual measurement size :38*(1——50)mm
3. Test spacing :1mm, 5mm, 10mm, 15mm, 20mm, 25mm, 30mm, 40mm, 50mm
4. Span accuracy :±0.1mm
5. Measuring range :0——1000g(0——10000mN) can be customized
6. Sensor: The sensing accuracy is 0.1%
7. Resolution :0.01mN
8. Bending Angle :1——95° no pole adjustable
9. Multi-functional measurement: stiffness/folding Wolf stiffness dual system
10. Angular speed control :0.5——5°/sec adjustable
11. Angle accuracy :±0.1°
12. Measure the maximum thickness :(0.01——5.0)mm
13. Bending time :(2——50s)
14. Operation interface :7inch touch screen or button test
15. Signal output: Standard computer signal output, link computer (optional)
16. Print output: modular integrated thermal printer
17. Dimensions :320mm*320mm*300mm
18. Net weight :28kg
