Geotextile Effective Aperture Tester
Scope of application:
The equivalent pore diameter of geotextile and its related products was determined by dry screening method. The geotextile sample is used as the screen cloth, the standard particle material with known diameter is placed on the geotextile above the vibrating screen, and the sieve rate is calculated by weighing the standard particle material weight of ten industrial cloth, and the sample is replaced by the standard particle material with different diameters. The aperture distribution curve of the textile is drawn and the value of 090 is obtained.
Meet the standard:
GB/T14799-2005.ASTM D4751-2004.JTG E50 T1144-2006.SL/T 235-7-2012. etc
Instrument features:
Adopts split type design to avoid damage to the control system caused by vibration during high-speed operation.
Using mechanical vibrating screen vibration, smooth and efficient;
Vibrating screen can carry out shaking and shaking two vibration modes, vibration frequency is stable;
Equipped with locking protection device, strengthen the stability of the fuselage;
It is equipped with an anti-static device to prevent glass beads from gathering on the surface of the sample due to electrostatic action;
+5 sets of sieve parallel sample test, energy saving and high efficiency;
Digital display time, vibration time can be set;
Easy to install, easy to operate.
Technical parameters:
The inner diameter of the screen is 200mm
The screen is made of aluminum
Screen stack height 400mm
Screen seat amplitude 8mm
Vibration frequency 221/min
Vibration frequency 147/min
Turning radius 12.5mm
The timer ranges from 0 to 99 minutes and 59 seconds
Power supply AC380V 50HZ
Dimensions Host 600x380x1000mm
Control box 330x290x105mm
Weight 130kg
