Aircraft wire wear testing machine
Applicable standards:
GJB17.9. MIL-W-81381A, MIL-T-5438 and ISO R1220. 1491 and other standards
Main parameters:
1. sand belt length counting range :0——9999.9mm
2. sand belt walking speed :1500 mm/min
3. grinding belt support rounded :F: 0.8/1.6/4.8mm G:0.4/0.8/1.6mm
4. test voltage :220V
5. load support weight :54+0.5g
6. The Angle between the sand belt and the sample :29°
7. conductive strip width :6.5mm
8. Distance between conductive strips :76+2mm
9. sand belt width :25+0.5mm
10. Sand belt length :50m
11. sand belt :400# alumina
12. Power supply :220V/50HZ
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
