Smoke - Emission Testing Machine for Aerospace Wires and Cables

Standards Compliance:

In accordance with the provisions of the U.S. military specifications MIL - W5086C and 22759D, as well as "GJB17.17 - 84 Test Methods for Aerospace Wires and Cables: Smoke - Emission Test".

Application Scope:

This testing machine is suitable for checking whether aerospace wires and cables emit visible smoke under the action of specified temperatures.

Technical Parameters:

1. Input voltage: AC220V + 10%, 50Hz

2. Operating DC current: Arbitrarily adjustable

(1) 0 - 400A (2KVA)

(2) 0 - 600A (3KVA) (This specification is optional)

(3) 0 - 1000A (12KVA) (This specification is optional)

3. Voltage drop range: 0 - 5000mV.

4. Timer: Adjustable within the range of 0 - 99.99H/M/S.

5. When the timing is up, the current can be automatically cut off.

6. Voltmeter range: DC0 - 5000mV, voltmeter accuracy: ±0.2%.

7. Ammeter range: 0 - 500A, ammeter accuracy: ±1%.

8. The test should be carried out in a wind - free environment.

9. Specifications of the smoke - emission combustion chamber: 1000mm×400mm×600mm, and the test background is black.
