Combustion Flue Gas Treatment System，ISO 14001 combustion flue gas cleaning and treatment system
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Combustion Flue Gas Treatment System is designed to purify flue gases generated during sample combustion in laboratory environments. This system integrates heat exchange, filtration, activated carbon adsorption, and UV photolysis to lower the temperature of the exhaust, remove solid particulates, eliminate odors, and ensure the emissions meet environmental standards before discharge.
Application
The Combustion Flue Gas Treatment System is suitable for:
Laboratory combustion experiments producing gaseous by-products.
Industrial sample burning where flue gas contains particulate matter, VOCs, or odors.
Testing and research scenarios requiring clean gas emission control.
Specific Testing Equipment:
Sample combustion furnace
Experimental reactors producing gas emissions
Thermal analysis instruments producing exhaust gases
Standards
The system conforms to the following international and national standards:
GB 16297-1996 – Comprehensive Emission Standard of Air Pollutants (China)
ISO 14001 – Environmental Management Systems
EN 1822 – High-Efficiency Air Filters (HEPA)
ASHRAE 52.2 – Method of Testing General Ventilation Air-Cleaning Devices for Removal Efficiency by Particle Size
Parameters
| Unit | Specification |
|---|---|
| Pre-filter Unit | Fiber felt (folded structure), removes large particulates; frame: aluminum/galvanized; Filtration grade: G2. G3; High-temperature and corrosion resistant, low resistance |
| Medium Filter Unit | Folded bag-type fine filter; frame: aluminum; Filtration grade: G3; single metal mesh support; low initial resistance, large capacity |
| High-Efficiency Filter Unit | Ultra-fine glass fiber filter paper; filters 0.1–0.3 μm particles; frame: galvanized or ABS; Filtration grade: H10. H13. H14; high dust capacity, low resistance |
| Dimensions | 6400 mm (W) × 1700 mm (L) × 1800 mm (H) |
| Power Supply | AC 380V, 25 KW |
| Weight | Approximately 2.5 T |
Features
Steel structure cabinet with sealed design for durability and aesthetics.
Side-opening doors for easy replacement of consumables.
Heat exchange cooling system with exhaust duct, fan, heat exchanger, circulation pump, and piping for efficient gas cooling.
Exhaust duct equipped with heat exchanger; circulating water absorbs heat from high-temperature gas for effective cooling.
Electrostatic precipitation captures oil smoke particles via electron emission and charged particle attraction, effectively removing oil mist.
UV photolysis system efficiently eliminates VOCs, inorganic pollutants, H₂S, NH₃, thiols, and other odors.
Activated carbon adsorption concentrates harmful combustion by-products on its surface for further purification.
Exhaust fan controlled by a frequency inverter ensures adjustable smoke extraction.
Accessories
Pre-filter panels (G2/G3)
Medium filter bags (G3)
High-efficiency HEPA filters (H10/H13/H14)
Heat exchanger unit
UV photolysis lamp assembly
Activated carbon adsorption module
Exhaust fan and ductwork
Circulating water pump and piping
Test Procedures
Install and check all filter units, heat exchangers, and UV lamps.
Connect the system to the combustion equipment producing flue gas.
Start circulation pump and ensure water flow to the heat exchanger.
Power on the exhaust fan and set the desired extraction rate via frequency inverter.
Begin combustion experiment; monitor gas temperature, flow, and pollutant removal efficiency.
Periodically check filter units for dust load and replace if necessary.
Ensure UV lamps and activated carbon module operate effectively for VOC and odor removal.
Maintenance Information
Inspect filters monthly; replace pre-filters and medium filters every 3–6 months depending on use.
Clean high-efficiency filters carefully to maintain filtration efficiency.
UV lamps should be checked for intensity and replaced annually or as per manufacturer’s recommendations.
Heat exchanger and water circulation system should be inspected regularly for blockages or leaks.
Check and lubricate exhaust fan bearings periodically.
Ensure activated carbon modules are replaced when adsorption efficiency declines.
Conclusion
The Combustion Flue Gas Treatment System provides a complete solution for laboratory and industrial flue gas purification. Combining multi-stage filtration, heat exchange, electrostatic precipitation, UV photolysis, and activated carbon adsorption, the system effectively removes particulate matter, VOCs, odors, and other pollutants, ensuring safe and standard-compliant emissions. Its robust design, efficient operation, and easy maintenance make it ideal for environmental control in combustion experiments.
