Carpet Flammability Testing Equipment
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Product Features
Flame-Resistant Chamber: Constructed from heat-resistant boards (380 × 380 × 380 mm).
Hot Nut Ignition: Stainless steel nut (30g, M16) heated to 900°C in a muffle furnace.
Polymer Sheet Method: Includes 230 × 230 mm metal plate with central hole for ignition.
Sliding/Fixed Panels: 280 × 380 mm sliding panel and 100 × 380 mm fixed panel for sample access.
45° Inclined Base: Simulates real-world carpet installation angles.
Safety Interlocks: Prevents chamber access during active testing.
Standard
BS 4790: Hot Metal Nut Method for Floor Covering Fabrics
ISO 6925: Ambient Temperature Tablet Test for Floor Coverings
BS 6307: Fire Test for Textile Floor Materials (Carpets/Rugs)
GB/T 11785: Flame Retardancy of Textile Floor Coverings
Technical Parameters
| Parameter | Specification |
|---|---|
| Control Mode | Automatic (PLC) |
| Test Chamber Size | 380 mm × 380 mm × 380 mm |
| Sample Clamping | Pneumatic (Adjustable Pressure) |
| Metal Plate | 230 × 230 × 6.5 mm (Central Ф205 mm Hole) |
| Ignition Nut | 30 g, M16 (Flat Diameter: 26.75–27.7 mm) |
| Sliding Panel | 280 × 380 mm (Flame-Retardant Glass) |
| Inclined Angle | 45° (Adjustable) |
| Power Supply | AC 220V ±10%, 50Hz |
| Dimensions (L×W×H) | 70 cm × 80 cm × 120 cm |
| Net Weight | 75 kg |
| Display | LED Touchscreen (Method Selection/Timer/Status) |
