Conduit Bending Test Machine

Whats/App: +86 156 1874 6768

Web: standard-groups.com

Application

The machine is widely used in:

Mechanical Performance Testing: Evaluate bending and torsion resistance of PV module conduits.

Safety Assessment: Verify conduit performance for PV module electrical safety.

R&D Durability Verification: Test conduit designs during development stages.

PV Module Certification: Compliant with IEC 61730-2 requirements.

Mechanical Stress Simulation: Assess conduit performance under installation and transportation forces.

Material and Structural Optimization: Verify the mechanical robustness of different conduit materials and designs.

Standards

IEC 61730-2:2004 – Photovoltaic (PV) Module Electrical Safety Requirements

Parameters

ItemTechnical Parameter
Controller Frequency Range 0–120 Hz
Spindle Rotational Speed N rev./min = Frequency Hz / 60 (e.g., 60 Hz → 1 rev./min)
Timer Range 1–9999 s
Power Supply Single-phase AC 220 V, 100 W
Conduit Outer Diameter & Weight 13–25 mm → 220 N; 26–50 mm → 330 N; 51–100 mm → 490 N

Features

Adjustable frequency control enables precise rotational speed.

Wide timer range suitable for long-duration endurance tests.

Standardized weights accommodate various conduit diameters.

Simple operation with high repeatability and reliability.

Suitable for research, production, and certification laboratories.

Accessories

Controller: Frequency setting 0–120 Hz for spindle speed adjustment.

Spindle: Supports stable rotation of conduits.

Weights: Standardized weights corresponding to conduit diameters (220 N, 330 N, 490 N).

Sample Fixture: Securely holds conduit to ensure safe and stable testing.

Timer: Range 1–9999 seconds, supports automatic stop.
