Cloth Bowing Evaluation Device
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
The instrument is widely used in:
Textile R&D: Quantifying fabric hand feel for product development.
Quality Control: Monitoring batch-to-batch consistency in textiles.
Apparel and Home Textiles: Assessing fabrics for clothing, bedding, and upholstery.
Nonwoven and Technical Fabrics: Evaluating stiffness and surface smoothness.
Educational and Research Institutions: Studying tactile properties of fibers, yarns, and fabrics.
Regulatory and Standards Organizations: Verifying compliance with hand-feel specifications.
Standards
T/CTES 1017-2019: Textile Hand Feel Evaluation Standard
FZ/T 01171-2023: Chinese Textile Hand Feel Instrument Test Method
ISO 9073-7: Textiles – Nonwovens – Determination of fabric hand properties (analogous international reference)
Features
Bionic Design: Cylindrical indenter simulates human fingertip touch with fine textures resembling fingerprints.
Three-Point Indenter Arrangement: One on top, two on the bottom, mimicking the natural way fingers contact fabric.
Multi-Deformation Analysis: Measures compressive, bending, frictional, and tensile responses.
Quantitative Output: Provides indicators for softness, stiffness, smoothness, tightness, and overall hand feel.
Single-Measurement Multi-Indicator: Evaluates multiple tactile parameters in a single test.
High Precision and Stability: Advanced components ensure reproducible results.
Easy Operation: Simple interface for quick testing with minimal setup.
After-Sales Support: Complete spare parts, prompt technical support, and compliance with updated standards.
Technical Parameters
| Parameter | Specification |
|---|---|
| Test Indicators | Softness, Stiffness, Smoothness, Tightness, Comprehensive evaluation |
| Sample Size | 50 × 500 mm |
| Sample Thickness | ≤ 4 mm |
| Single Measurement Time | ~4 minutes |
| Test Environment | 20 ± 3 ℃; 60 ± 5 % RH |
| Dimensions (W×D×H) | 500 × 480 × 780 mm |
| Power Supply | AC 220V ±10%, 50Hz |
| Power Consumption | 100 W |
| Instrument Weight | 50 kg |
Accessories
Cylindrical indenter set with fingerprint texture
Adjustable sample holder
Force-displacement data acquisition system
Software for quantitative analysis and report generation
Calibration tools and manuals
