ISO 7148 Heavy-Duty Reciprocating Friction and Wear Testing Machine Supplier
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Heavy-Duty Reciprocating Friction and Wear Testing Machine is a high-performance tribological testing instrument designed to study friction and wear behaviors of materials and surface coatings under various working conditions. The machine utilizes automatic loading and reciprocating motion, capable of testing under high load, high frequency, and high-temperature conditions. It precisely measures parameters such as friction force, coefficient of friction, and wear volume, and is widely used in material science, mechanical engineering, aerospace, metallurgy, and quality control applications.
Standards
GB/T 3960-2016 Test Methods for Sliding Friction and Wear of Plastics
GB/T 14887-1993 General Technical Requirements for Tribological Testing Equipment
ASTM G99-17 Standard Test Method for Wear”
ASTM G133-13 Standard Test Method for Reciprocating Friction and Wear
DIN 50324 Friction and Wear Test Methods”
ISO 7148-2 Tribology – Test Methods – Part 2: Test Procedures
ISO 6743-8 Lubricants – Classification
EN 13672 Artificial Turf Friction Performance Test Methods
SAE J3065 Test Method for Engine Oil Friction Characteristics
Parameters
| Parameter | Technical Specification |
|---|---|
| Maximum Reciprocating Frequency | 10 Hz |
| Maximum Stroke | 10 mm |
| Maximum Friction Force | 1000 N |
| Maximum Load | 1500 N |
| Friction Pair Type | Block-on-Ring |
| Time Control Range | 1 s – 9999 h |
| Temperature Heating Range | Ambient – 600°C (with high-temperature furnace) |
| Loading Method | Automatic Loading |
Features
High-load capability: supports up to 1500 N test force for heavy-duty friction and wear testing.
Broad temperature adaptability: capable of testing from ambient temperature to 600°C.
Automatic loading system: ensures stable load during testing.
Real-time data acquisition and report generation: accurate, transparent, and automatic reporting.
Multiple friction pair configurations: supports block-on-ring and other friction pair types.
Flexible test condition settings: adjustable load, temperature, and frequency to simulate various real-world conditions.
Accessories
| Accessory | Specification/Description |
|---|---|
| Heating Furnace | ±2°C accuracy, maximum 600°C |
| Friction Pair Materials | Metal, ceramic, plastic, etc. |
| Test Samples | Selected based on testing requirements |
| Loading Module | Automatic loading, adaptable to different tests |
| Control Software | Provides data acquisition and report generation |
